VED.101 motor launches (1941 - 1942 / 1942 - 1943)





Ved.101

Ships


Names Builders Completed Losses Transfers Discarding

Ved.101 St. Ronan (ex-ML244), 1950- P775

Ved.102 St. Yves  (ex-ML271), 1950- P776

Ved.103 St. Guénolé (ex-ML266), 1950- P777

Ved.104 St. Alain (ex-ML302), 1950- P779

ML123

ML182

ML205

ML245 - 247

ML267 - 269

ML303

V111 Galantry (ex-ML052)

V112 Langdale (ex-ML062)

V113 Colombier (ex-ML063)

H. J. Percival, Horning, UK: Ved.101

Boat Construction Co., Falmouth, UK: Ved.102

King, Burnham, UK: Ved.103, 104

Curtis, Looe, UK: ML123

Leo Robertson, Tewkesbury: ML182

Jas Taylor, Chertsey, UK: ML205

Sheerness DYd, UK: ML245, 246

J. W. & A. Upham, Brixham, UK: ML247

Solent SYd, Sarisbury Green, UK: ML267

Dorset Yacht, Hamworthy, UK: ML268

William Weatherhead, Cockenzie, UK: ML269

Jas Miller, St. Monace, UK: ML303

Taylor, Toronto, Canada: V111

Mac Craft, Sarnia, Canada: V112, 113

1941 / 1942: ML123, 182, 205, 245 - 247, 267 - 269, 303

1941 / 1943: Ved.101 - 104, V111

1942 / 1943: V112, 113

ML267 (28.3.1942), ML268 (28.3.1942)

United Kingdom, 7 - 8.1942: ML123, 182, 205, 245 - 247, 267 - 269, 303 (ML123, 182, 205, 245 - 247, 267 - 269, 303)

Canada, 1945: V112 Langdale (ML062)

late 1940s: V111 Galantry, V113 Colombier

1951: P775 - 777

1955: P779



Technical data


Displacement standard, t

75.5

Displacement full, t85.6
Length, m34.8
Breadth, m5.59
Draught, m1.45 deep load
No of shafts2
Machinery

2 Hall-Scott petrol engines

Power, h. p.1200
Max speed, kts

18

Fuel, t

petrol 10500 l

Endurance, nm(kts)
Armament

1 x 1 - 47/40 3pdr Hotchkiss Mk I, 1 x 1 - 20/70 Oerlikon Mk II/IV, 2 x 2 - 7.7/87, 1 DCR (12)

Electronic equipment

commissioned 1942: type 134 sonar

commissioned 1942-1943: type 286PU radar, type 134 sonar

Complement16


Standard scale images


<i>V111 Galantry</i> 1943
V111 Galantry 1943


Graphics


<i> Ved.101</i>
Ved.101


Project history

Ex-British and Canadian MLs of Fairmile B type.

Modernizations

1943-1944, most survived: - type 286PU radar; + type 291U or type 293 radar

Naval service

ML267 and ML268 were sunk in St-Nazaire raid 28.3.1942.
