KAMPELA 1 landing craft (1976-1979)
Kampela 2 2000
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| Kampela 1 | 371, 2000s- 771 | Enso-Gutzeit, Savonlinna | 29.7.1976 | stricken 2009 | |||
| Kampela 2 | 376, 2000s- 772 | Enso-Gutzeit, Savonlinna | 21.10.1976 | stricken 2011 | |||
| Kampela 3 | 557, 2000s- 877 | Finnmekano, Teija | 23.10.1979 | in service (2019) |
Technical data
| Displacement standard, t | 90 |
|---|---|
| Displacement full, t | 260 |
| Length, m | 32.5 |
| Breadth, m | 8.00 |
| Draught, m | 1.50 |
| No of shafts | 2 |
| Machinery | 2 Saab-Scania diesels |
| Power, h. p. | 460 |
| Max speed, kts | 9 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | |
| Armament | 1 x 2 - 23/87 Sako, 20 mines instead of cargo |
| Military load | ~120 t of cargo |
| Electronic equipment | Decca 1226 radar |
| Complement | 10 |
Standard scale images
Kampela 2 2000
Graphics
Kampela 2 2000
Project history
Small LCUs. Can be used as coastal transports, amphibious craft, minelayers or for shore support.
Modernizations
2000s, all: - 1 x 2 - 23/87; + 2 x 1 - 12.7/79
Naval service
No significant events.
