NAVYPEDIA


Isku 1979

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Isku	16, 1990s- 826, 2003- 829		Reposaaren Konepaja, Pori	11.1968	4.12.1969	1970	minelayer / trial ship 1990, in service (2019)

Technical data

Displacement standard, t	115
Displacement full, t	140
Length, m	26.4 wl 28.0 oa
Breadth, m	8.70
Draught, m	1.80
No of shafts	4
Machinery	4 M-50F-4 diesels
Power, h. p.	4400
Max speed, kts	15
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	4 x 1 P-20 SSM (4 P-20), 1 x 2 - 30/71 AK-230
Electronic equipment	Rangout, Raytheon radars
Complement	15

Standard scale images

Graphics

Project history

Landing craft hull designed for SSMs and more powerful engines.

Modernizations

1990: craft was lengthened (180t full, 33.4x8.7x1.8m, 18kts); - 4 x 1 P-20 SSM, 1 x 2 - 30/71, Rangout radar; + 2 mine rails

Naval service

Isku never reached her designed speed and served only as test craft.
