DAGMAR screw sloop (1862)





Dagmar

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Dagmar     Orlogsværftet, København 1860 1.11.1861 1862 stricken 7.1901


Technical data


Displacement normal, t

1175

Displacement full, t

1222

Length, m

54.4

Breadth, m

10.3

Draught, m

5.0

No of shafts

1

Machinery

1 HDA

Power, h. p.

500

Max speed, kts

9

Fuel, t

coal

Endurance, nm(kts)
Armament

16 x 1 - 167/15.9 30pdr 60ctr 2.946 Ton Armstrong SB

Complement

190



Graphics


<i>Dagmar</i>
Dagmar


Project history

Wooden screw sloop, rated in Dutch Navy as corvette.

Modernizations

1864: - 2 x 1 - 167/15.9; + 2 x 1 - 143/ 18pdr 40ctr 1.964 Ton MLR

~1866: - 14 x 1 - 167/15.9, 2 x 1 - 143/ ; + 8 x 1 - 153/19 24pdr 62ctr 3.044 Ton Akers M1864 BLR

1885: new armament consisted of 8 x 1 - 120/27 RK L/30 C/84, 2 x 5 - 37/17 M.1875

Naval service

No significant events.

Many Thanks to Kent Crawford for unique correction of information about ship's guns on this page.
