NAVYPEDIA


20 de Julio 1975

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
20 de Julio (Veinte de Julio)	D05		Kockums, Malmö, Sweden	10.1955	26.6.1956	15.6.1958	discarded 1984
7 de Agosto (Siete de Agosto) (ex-3 de Junio (Trece de Junio))	D06		Götaverken, Göteborg, Sweden	11.1955	19.6.1956	31.10.1958	discarded 1986

Technical data

Displacement standard, t	2650
Displacement full, t	3300
Length, m	121.1
Breadth, m	12.4
Draught, m	4.70
No of shafts	2
Machinery	2 sets De Laval double geared steam turbines, 2 Penhoët boilers
Power, h. p.	55000
Max speed, kts	32
Fuel, t	oil 524
Endurance, nm(kts)	3000(18)
Armament	3 x 2 - 120/50 M50, 4 x 1 - 40/70 M48, 1 x 4 - 533 TT, 1 x 4 - 375 M50 ASWRL
Electronic equipment	LW-03/SGR-114, DA-02/SGR-105, 6x M45 radars, sonar
Complement	248

Standard scale images

Graphics

Project history

Ordered in 1954, these units were modified Halland class destroyers. They mourned a different armament, more electronics, and different interior arrangements than their near sisters in Sweden. Dutch electronics, with M4 type radar directors for gun armament. 2 x 6 - 103 RFLs on 120mm turrets.

Modernizations

None.

Naval service

No significant events.
