11 de Noviembre 2001

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
11 de Noviembre	PC145		Fassmer, Berne/Motzen, Germany		21.1.2011	9.5.2011	in service (2019)

Technical data

Displacement standard, t	200
Displacement full, t	245
Length, m	40.0
Breadth, m	7.40
Draught, m	2.35
No of shafts	2
Machinery	2 MTU 12V4000 M73 diesels
Power, h. p.	5220
Max speed, kts	23
Fuel, t	diesel oil
Endurance, nm(kts)	2000(12)
Armament	1 x 1 - 25/75 Typhoon-G mod.2, 2 x 1 - 12.7/90
Electronic equipment	2x Furuno radars, Toplite e/o system
Complement	24

Standard scale images

Graphics

Project history

Fassmer CPV40 design. Steel hull, aluminium superstructure. Carries Avon Searider 5.40m fast RIB onboard.

Modernizations

None.

Naval service

No significant events.
