GUACOLDA fast attack craft (torpedo) (1965-1966)





Quidora 1979

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Guacolda 80, 12.1997- LSG1605   Izar, San Fernando, Spain 1963 1964 7/1965 Coast Guard 12.1997, stricken 2007
Fresia 81, 12.1997- LSG1606   Izar, San Fernando, Spain 1963 1964 12/1965 Coast Guard 12.1997, stricken 2007
Quidora 83, 12.1997- LSG1607   Izar, San Fernando, Spain 1964 1965 3/1966 Coast Guard 12.1997, stricken 2001
Tegualda 84, 12.1997- LPM1608   Izar, San Fernando, Spain 1964 1965 7/1966 Coast Guard 12.1997, stricken 2002


Technical data


Displacement standard, t
Displacement full, t

134

Length, m

34.0 wl 36.2 oa

Breadth, m

5.60

Draught, m

1.68

No of shafts

2

Machinery

2 Mercedes-Benz MB839Bd diesels

Power, h. p.

4800

Max speed, kts

32

Fuel, t

diesel oil

Endurance, nm(kts)

1500(15)

Armament

2 x 1 - 40/70 Bofors 315, 4 - 533 TT

Electronic equipment

Decca 505 radar

Complement

20



Standard scale images


<i>Fresia </i>1975
Fresia 1975


Graphics


<i>Quidora </i>1979
Quidora 1979
<i>Fresia </i>2001
Fresia 2001


Project history

Designed by Lürssen, these craft served in the Beagle Channel. The TT were British Mk IV.

Modernizations 12.

1997, all: - 1 x 1 - 40/70, 4 - 533 TT; + 2 x 1 - 12.7/90, RIB launch with crane.

Naval service

No significant events.
