NAVYPEDIA


Arica 2004

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Aysén	LSG1609		ASMAR, Talcahuano			1999	in service (2019)
Corral	LSG1610		ASMAR, Talcahuano			2000	in service (2019)
Concepción	LSG1611		ASMAR, Talcahuano			2000	in service (2019)
Caldera	LSG1612		ASMAR, Talcahuano			2000	in service (2019)
San Antonio	LSG1613		ASMAR, Talcahuano			2000	in service (2019)
Antofagasta	LSG1614		ASMAR, Talcahuano			2001	in service (2019)
Arica	LSG1615		ASMAR, Talcahuano			2001	in service (2019)
Coquimbo	LSG1616		ASMAR, Talcahuano			2001	in service (2019)
Puerto Natales	LSG1617		ASMAR, Talcahuano			26.2.2002	in service (2019)
Valparaíso	LSG1618		ASMAR, Talcahuano			2002	in service (2019)
Punta Arenas	LSG1619		ASMAR, Talcahuano			1.8.2002	in service (2019)
Talcahuano	LSG1620		ASMAR, Talcahuano			25.10.2002	in service (2019)
Quintero	LSG1621		ASMAR, Talcahuano			2003	in service (2019)
Chiloé	LSG1622		ASMAR, Talcahuano			2003	in service (2019)
Puerto Montt	LSG1623		ASMAR, Talcahuano			17.12.2003	in service (2019)
Iquique	LSG1624		ASMAR, Talcahuano			10.3.2004	in service (2019)

Technical data

Displacement standard, t	100
Displacement full, t	120
Length, m	29.0 wl 33.1 oa
Breadth, m	6.73
Draught, m	1.95
No of shafts	2
Machinery	2 MTU 16V2000 M90 diesels
Power, h. p.	3200
Max speed, kts	27
Fuel, t	diesel oil 22
Endurance, nm(kts)	1400(14)
Armament	2 x 1 - 12.7/90
Electronic equipment	Decca or Furuno FR-701 radar
Complement	10 + 18 passengers

Graphics

Project history

Danubio 1 design, locally derived from Protector 33 class.

Modernizations

None.

Naval service

No significant events.
