Vigilante 2007 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Vigilante (ex-GS07, ex-Kühlungsborn)	P521	238	Peenewerft, Wolgast, East Germany	9.9.1969	14.1.1970	3.6.1970 // 25.9.1998	in service (2020)

Technical data

Displacement standard, t	330
Displacement full, t	380
Length, m	52.0
Breadth, m	7.10
Draught, m	2.40
No of shafts	2
Machinery	2 40DM diesels
Power, h. p.	4400
Max speed, kts	20
Fuel, t	diesel oil
Endurance, nm(kts)	2200(11)
Armament	1 x 2 - 23/82 ZU-23, helicopter deck
Electronic equipment	Decca 360 radar
Complement	12

Standard scale images

Graphics

Project history

Former Volksmarine's minesweeper of Kondor I class. After unification she was stricken in 1996, transferred unarmed to Cape Verde in May 1998, received armament after transfer and commissioned 25.9.1998.

Modernizations

None.

Naval service

: No significant events.
