RKA-20 missile attack craft (project 205) (1965-1966/1971), RKA-23 missile attack craft (project 205U) (1960s-1970s/1977-1984)


Buria 2002

Name	No	Yard No	Builder	Comp	Fate	Modification
РКА-20 [RKA-20] (ex-Р-30 [R-30]), 12.1985- Смерч [Smerch]	113, 2005- 107	464	Primorskiy Yd, Leningrad, USSR	1965 // 4.1971	stricken 6.2008	Project 205
РКА-21 [RKA-21] (ex-Р-73 [R-73]), 12.1985- Гръм [Grum]	112, 2005- 106	439	5 Yd, Leningrad, USSR	1965 // 4.1971	stricken 2012-15	Project 205
РКА-22 [RKA-22] (ex-Р-176 [R-176]), 12.1985- Буря [Buria]	103, 2005- 105		Primorskiy Yd, Leningrad, USSR	1966 // 4.1971	stricken 2012-15	Project 205
РКА-23 [RKA-23] (ex-Р-169 [R-169]), 1981- РКА-13 [RKA-13], 12.1985- Ураган [Uragan]	102		USSR	1960s-1970s // 2.1977	stricken 2012-15	Project 205U
РКА-11 [RKA-11] (ex-Р-496 [R-496]), 12.1985- Светкавици [Svetkavitsi]	101, 1990- 104, 2005- 103		USSR	1960s-1970s // 1.1982	stricken 2012-15	Project 205U
РКА-12 [RKA-12] (ex-Р-255 [R-255]), 12.1985- Тайфун [Tayfun]	111, 2005- 104	469	5 Yd, Leningrad, USSR	1965 // 1984	stricken 6.2008	Project 205U

Displacement standard, t	pr. 205: 184 pr. 205U: 192
Displacement full, t	pr. 205: 226 pr. 205U: 235
Length, m	38.6
Breadth, m	7.60
Draught, m	1.84
No of shafts	3
Machinery	3 M-504B diesels
Power, h. p.	15000
Max speed, kts	42
Fuel, t	diesel oil
Endurance, nm(kts)	1800(14)
Armament	pr. 205: 4 x 1 P-15/P-15T SSM (4 P-15/P-15T), 2 x 2 - 30/71 AK-230 pr. 205U: 4 x 1 P-15U SSM (4 P-15U), 2 x 2 - 30/71 AK-230
Electronic equipment	MR-101 Rangout, MR-104 Rys' radars
Complement	pr. 205: 28 pr. 205U: 29
