FIGHTING SHIPS OF THE WORLD
BULGARIA
COASTAL FORCES
MULNIYA missile attack craft (project 12411T) (1982/1989)
Mulniya 2000
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| Мълния [Mulniya] (ex-Полтавский комсомолец [Poltavskiy Komsomolets], ex-Р-256 [R-256]) | 101, 2005- 43, 2008- 101 | 404 | Almaz, Leningrad, USSR | 1982 // 12.1989 | in service (2019) |
Technical data
| Displacement standard, t | 392 |
|---|---|
| Displacement full, t | 469 |
| Length, m | 56.1 |
| Breadth, m | 10.2 |
| Draught, m | 2.25 |
| No of shafts | 2 |
| Machinery | 2 M-15 gas turbine units (each consist of M-75 cruising gas turbine and M-70 boost gas turbine) |
| Power, h. p. | 10000 + 24000 = 34000 |
| Max speed, kts | 42 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 1600(14) |
| Armament | 2 x 2 P-15M Termit SSM (4 4K51), 1 x 4 Strela-3M SAM (16 9M36M), 1 x 1 - 76/59 AK-176M, 2 x 6 - 30/54 AK-630M |
| Electronic equipment | Monolit-T radar suite, MR-123 Vympel-A, MR-405, Don radars, Vympel-R2 ECM suite, 2x PK-16 decoy RL |
| Complement | 41 |
Standard scale images
Mulniya 1990
Graphics
Mulniya 2000
Project history
Former Soviet project 12411T FAC(M), classified in Bulgarian Navy as corvette.
Modernizations
None.
Naval service
No significant events.
