Abdul Rahman Al Fadel 2009

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
أحمد الفاتح [Ahmed Al Fateh]	20		Lürssen, Vegesack, West Germany			5.2.1984	in service (2020)
الجابري [Al Jaberi]	21		Lürssen, Vegesack, West Germany			3.5.1984	in service (2020)
عبدال رحمن الفاضل [Abdul Rahman Al Fadel]	22		Lürssen, Vegesack, West Germany			10.9.1986	in service (2020)
الطويله [Al Taweelah]	23		Lürssen, Vegesack, West Germany			25.3.1989	in service (2020)

Technical data

Displacement standard, t	228
Displacement full, t	259
Length, m	42.3 pp 44.9 oa
Breadth, m	7.30
Draught, m	2.30
No of shafts	4
Machinery	4 MTU 16V538 TB92 diesels
Power, h. p.	14400
Max speed, kts	40.5
Fuel, t	diesel oil 45
Endurance, nm(kts)	1600(16)
Armament	2 x 2 MM40 Exocet SSM (4 MM40), 1 x 1 - 76/62 OTO-Melara Compact, 1 x 2 - 40/70 Breda-Bofors Compact Twin 40, 2 x 1 - 12.7/90
Electronic equipment	20, 21: Decca 1226, 9LV331 (9LV200 radar with e/o system), Sea Giraffe 50HC radars, Panda e/o system, RDL-2 ECM suite, Dagaie decoy RL 22, 23: Decca 1226, 9LV331 (9LV200 radar with e/o system), Sea Giraffe 50HC radars, Panda e/o system, Cutlass B-1, Cygnus ECM suites, Dagaie decoy RL
Complement	32

Standard scale images

Graphics

Project history

Lürssen TNC45 type, ordered in 1979 (first pair) and in 1985 (second pair). Can be fitted for minelaying.

Modernizations

None.

Naval service

No significant events.
