FIGHTING SHIPS OF THE WORLD
BAHAMAS
COASTAL FORCES
P48 patrol launches (2008)
P48 2008
Ships
| Names | Builders | Commissioned | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
P48, 49 |
SeaArk, Monticello, USA: P48, 49 |
2008: P48, 49 |
none |
None |
in service (2020): P48, 49 |
Technical data
| Displacement standard, t | |
|---|---|
| Displacement full, t | 17 |
| Length, m | 14.9 |
| Breadth, m | 5.25 |
| Draught, m | 1.40 |
| No of shafts | 2 |
| Machinery | 2 Caterpillar C12 diesels |
| Power, h. p. | 1320 |
| Max speed, kts | 30 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 300(12) |
| Armament | 2 x 1 - 7.6/90 |
| Electronic equipment | Furuno radar |
| Complement | 6 |
Graphics
P48 2008
Project history
SeaArk Dauntless RAM design. Aluminium construction.
Modernizations
None.
Naval service
No significant events.
