NAVYPEDIA


D431 2012

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate	Modification
(ex-МДК-36 [MDK-36], ex-СДК-36 [SDK-36])	D431	770MA/26	Stocznia Północna, Gdańsk, Poland	15.4.1965	12.1.1966	11.6.1966 // 3.7.1992	in service (2020)	Project 770MA
(ex-МДК-37 [MDK-37], ex-СДК-37 [SDK-37])	D432	770MA/27	Stocznia Północna, Gdańsk, Poland	10.5.1965	5.2.1966	24.6.1966 // 3.7.1992	in service (2020)	Project 770MA
(ex-МДК-68 [MDK-68], ex-СДК-68 [SDK-68])	D434	770T/4	Stocznia Północna, Gdańsk, Poland	1.2.1965	22.12.1965	31.5.1966 // 3.7.1992	stricken 2016	Project 770T

100 - 1000 t displacement/ BRT tonnage vessels

Name No Yard No Builder Laid down Launched Comp Fate Project 770MA(ex-МДК-36 [MDK-36], ex-СДК-36 [SDK-36]) D431 770MA/26 Stocznia Północna, Gdańsk, Poland 15.4.1965 12.1.1966 11.6.1966 // 3.7.1992 in service (2020) (ex-МДК-37 [MDK-37], ex-СДК-37 [SDK-37]) D432 770MA/27 Stocznia Północna, Gdańsk, Poland 10.5.1965 5.2.1966 24.6.1966 // 3.7.1992 in service (2020) Project 770T(ex-МДК-68 [MDK-68], ex-СДК-68 [SDK-68]) D434 770T/4 Stocznia Północna, Gdańsk, Poland 1.2.1965 22.12.1965 31.5.1966 // 3.7.1992 stricken 2016

Technical data

Displacement standard, t	pr. 770T: 704 pr. 770MA: 772
Displacement full, t	pr. 770T: 751 pr. 770MA: 820
Length, m	73.0
Breadth, m	8.62
Draught, m	pr. 770T: 1.85 pr. 770MA: 1.98
No of shafts	2
Machinery	2 40D diesels
Power, h. p.	4400
Max speed, kts	18.5
Fuel, t	diesel oil
Endurance, nm(kts)	1800(16)
Armament	pr. 770T: 4 x 4 Strela-2M SAM (32 9M32M), 2 x 18 - 140 WM-18 RL pr. 770MA: 4 x 4 Strela-2M SAM (32 9M32M), 2 x 2 - 30/71 AK-230, 2 x 18 - 140 WM-18 RL
Military load	4 heavy or 5 medium tanks or 9 trucks
Electronic equipment	pr. 770T: Donets radar pr. 770MA: Donets, MR-104 Rys' radars
Complement	42

Standard scale images

Graphics

Project history

Former Soviet projects 770T and 770MA medium (later small) landing ships.

Modernizations

None.

Naval service

No significant events.
