Trabant 1916 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Trabant		254	STT, San Rocco	1889	21.5.1890	10/1890	minesweeper 1915, to Italy 1920

Technical data

Displacement normal, t	490
Displacement full, t	540
Length, m	67.0 wl 65.5 pp
Breadth, m	8.00
Draught, m	2.40
No of shafts	2
Machinery	2 VTE, 4 locomotive boilers
Power, h. p.	3800
Max speed, kts	20.1
Fuel, t	coal
Endurance, nm(kts)	2300(10)
Armament	2 x 1 - 66/37 SFK L/42 S, 8 x 1 - 47/40 SFK L/44 H, 1 - 450 TT (bow), 1 x 1 - 450 TT
Complement	84

Standard scale images

Graphics

Project history

Officially classified as "torpedo ship". Austrian development of Planet.

Modernizations

1915: + mechanical minesweeping gear

Naval service

No significant events.
