NATTER torpedo boat (1896)
No18 1914 Many thanks to Wolfgang Stöhr for additional information on this page.
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| Natter, 1910- 18 | 577 | Schichau, Elbing, Germany | 1/1895 | 3/1896 | 11/1896 | to United Kingdom 1920 |
Technical data
| Displacement normal, t | 166 |
|---|---|
| Displacement full, t | |
| Length, m | 47.3 wl |
| Breadth, m | 5.30 |
| Draught, m | 2.80 |
| No of shafts | 1 |
| Machinery | 1 VTE, 2 Schulz-Thornycroft boilers |
| Power, h. p. | 2200 |
| Max speed, kts | 24 |
| Fuel, t | coal 30 |
| Endurance, nm(kts) | 2600(12) |
| Armament | 2 x 1 - 47/30 SFK L/33 H, 3 x 1 - 450 TT |
| Complement | 21 |
Standard scale images
Natter 1896
Graphics
No18 1914 Many thanks to Wolfgang Stöhr for additional information on this page.
Project history
Schichau-built TB.
Modernizations
1911: - 2 x 1 - 47/40, 1 x 1 - 450 TT
Naval service
After 1910 18 served as mobile torpedo battery at Pola.
