NAVYPEDIA


IV

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
III IV	Yarrow, Poplar, UK: III, IV	1879: III, IV	none	none	1904: III, IV

Technical data

Displacement normal, t	27
Displacement full, t
Length, m	26.4
Breadth, m	3.30
Draught, m	1.50
No of shafts	1
Machinery	1 HC, 1 locomotive boiler
Power, h. p.	430
Max speed, kts	17.5
Fuel, t	coal
Endurance, nm(kts)
Armament	2 - 356 TT (bow)
Complement	10

Standard scale images

Graphics

Project history

Yarrow-built prototypes, launched in September 1879, variant of the Lightning.

Modernizations

None.

Naval service

No significant events.
