100M 1918 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
98M		55	CNT, Monfalcone // Marinearsenal Pola	3/1914	18.11.1914	8/1915	to Greece 1920 (Κύζικος [Kyzikos])
99M		56	CNT, Monfalcone // Marinearsenal Pola	3/1914	17.12.1914	10/1915	to Greece 1920 (Κίος [Kios])
100M		57	CNT, Monfalcone // Marinearsenal Pola	3/1914	15.1.1915	3/1916	to Greece 1920 (Κυδωνίαi [Kidoniai])

Technical data

Displacement normal, t	270
Displacement full, t	330
Length, m	60.5 wl 59.9 pp
Breadth, m	5.60
Draught, m	1.50
No of shafts	2
Machinery	2 Melms-Pfenninger steam turbines, 2 Yarrow boilers
Power, h. p.	5000
Max speed, kts	29.5
Fuel, t	coal 18 + oil 24
Endurance, nm(kts)	1200(16)
Armament	2 x 1 - 66/27 G. L/30 K.09, 1 x 1 - 8.80, 2 x 2 - 450 TT, 10 - 12 mines
Complement	38

Standard scale images

Graphics

Project history

Built by Cantiere Navale Triestino at Monfalcone. Initially only the numbers 82-85 should have been built by Danubius, with the series 86-100 allocated io the Pola N Yd, but when Danubius was ordered to build 16 units after the intervention of the Hungarian Ministry of Commerce, the remaining units were ordered from Cantiere Naval Triestino.

Modernizations

1917, all: - 1 x 1 - 66/27; + 1 x 1 - 75/27 G. L/30 K.16 BAG

Naval service

They saw active service during the war. All three survived and they were sold to Greece in 1920 and renamed Kyzikos, Kios and Kidoniai. Kios damaged by German bombs on 23 April 1941 and scuttled; Kyzikos was scuttled on 25 April 1941 at the Greek Navy yard at Salamis; and Kidoniai sank after German bomb hits on 26 April 1941.
