ZRÍNYI sloops (1871-1874)





Frundsberg 1893 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Zrínyi   80 STT, San Rocco 17.1.1870 10.12.1870 26.8.1871 TS 1900, hulk 1905
Frundsberg     STT, San Rocco 19.6.1871 11.2.1873 10/1873 TS 1900, stricken 1904
Aurora     STT, San Rocco 11.11.1871 20.11.1873 1.7.1874 accommodation hulk 1902


Technical data


Displacement normal, t

1353

Displacement full, t
Length, m

69.1 oa 59.1 pp

Breadth, m

10.5

Draught, m

5.00

No of shafts

1

Machinery

1 2-cyl HSE, cylindrical boilers

Power, h. p.

Zrinyi, Frundsberg: 1000

Aurora: 1165

Max speed, kts

Zrinyi, Frundsberg: 11

Aurora: 11.2

Fuel, t

coal 155

Endurance, nm(kts)1200(10)
Armament

4 x 1 - 149/18 G. L/21 M.61, 2 x 1 - 66/16 G. L/18

Complement

210



Standard scale images


<i>Aurora</i><i> </i> 1874
Aurora 1874


Graphics


<i>Frundsberg </i>1893 <i>Many thanks to Wolfgang Stöhr for additional information on this page.</i>
Frundsberg 1893 Many thanks to Wolfgang Stöhr for additional information on this page.


Project history

Typical screw sloops.

Modernizations

1880s, all: + 2 x 5 - 25/41 Nordenfelt

1891, all: - 2 x 1 - 149/18, 2 x 5 - 25/41; + 4 x 1 - 87/22 G. L/24 M.75, 2 x 5 - 47/22 SFK L/25 H

Naval service

Aurora in 1902 was converted to accommodation hulk, in 1905 to mine depot, went to Yugoslavia in 1920, enamed Skradin and scrapped in 1927. Frundsberg became a hulk in 1905, served as mine storage ship at Sibenik during the First World War, and was ceded to Yugoslavia in 1920, renamed Zlarin; her fate after April 1941 is unknown. Zrínyi became a hulk in 1905, and in 1908 she was renamed Delta when her name was needed for a new dreadnought. During the First World War she served as a mine storage ship at Pola she was accidentally foundered at Pola in 1920.

Many thanks to Wolfgang Stöhr for additional information on this page.
