GC100 patrol boats (1976)
Ships
| Names | Builders | Commissioned | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
GC100 GC112-114 GC221, 1995- 321 نضجمة الكتب [Nedjmet El Kotb] GC222, 1995- 328 إطار [Etair] GC235, 1995- 325 الحامل [El Hamil] GC236, 1995- 326 الأسد [El Assad] GC237, 1995- 327 ماركهد [Markhad] GC329, 1995- 329 آخر نهر [Akhir Nahr] |
Baglietto, Varazze, Italy: GC100, 112-114, 221, 222, 235-237, 329 |
1976: GC100, 112-114, 221, 222, 235-237, 329 |
none |
none |
1995: GC100, 112-114 in service (2019): 321, 325-329 |
Technical data
| Displacement standard, t | |
|---|---|
| Displacement full, t | 42 |
| Length, m | 20.1 |
| Breadth, m | 5.20 |
| Draught, m | 1.70 |
| No of shafts | 2 |
| Machinery | 2 CRM 18DS diesels |
| Power, h. p. | 2700 |
| Max speed, kts | 35 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 445(20) |
| Armament | 1 x 1 - 20/70 Mk 10 |
| Electronic equipment | radar |
| Complement | 11 |
Graphics
Project history
Baglietto type 20. Coast Guard.
Modernizations
None.
Naval service
No significant events.
