RAÏS HAMIDOU corvettes (1980-1982)





Salah Rais 2007 (no Uran canisters onboard)

Ships


Name No Yard No Builder Laid down Launched Comp Fate
رئس حميدو [Rais Hamidou] (ex-МРК-21 [MRK-21]) 801 201 Vympel, Rybinsk, USSR 10.3.1978 28.8.1979 31.12.1979 // 4.7.1980 in service (2019)
صلاح رئس [Salah Rais] (ex-МРК-23 [MRK-23]) 802 202 Vympel, Rybinsk, USSR 17.8.1978 31.7.1980 31.10.1980 // 9.2.1981 in service (2019)
رئس علي [Rais Ali] (ex-МРК-22 [MRK-22]) 803 204 Vympel, Rybinsk, USSR 4.4.1980 13.8.1981 30.11.1981 // 8.5.1982 in service (2019)


Technical data


Displacement standard, t

560
Displacement full, t

700
Length, m

59.3
Breadth, m

11.8
Draught, m

2.74
No of shafts

3
Machinery

3 M-507 diesels
Power, h. p.

25800
Max speed, kts

34
Fuel, t

diesel oil
Endurance, nm(kts)

2500(12)
Armament

2 x 2 P-20 Termit SSM (4 P-20), 1 x 2 Osa-M SAM (20 9M33), 1 x 2 - 57/50 AK-725
Electronic equipment

Rangout-E, 4R-33, MR-103 Bars, Don radars, 2 PK-16 decoy RL
Complement

49


Standard scale images


<i>Raïs Hamidou </i>1990
Raïs Hamidou 1990
<i>Salah Rais </i>2015
Salah Rais 2015


Graphics


<i>Salah Rais </i>2007 (no Uran canisters onboard)
Salah Rais 2007 (no Uran canisters onboard)


Project history

Soviet-built little missile ships of export project 1234E.

Modernizations

2000, Salah Rais under project 1234EM: - 2 x 2 P20 Termit SSM, Rangout-E, MR-103 Bars radars, 2x PK-16 decoy RL; + 4 x 4 Uran SSM (16 3M24E), 1 x 6 - 30/54 AK-630M, Pozitiv-ME1, 3Ts-25E Garpun-E radars, Laska-E, SP-521 Rakurs e/o systems, 2x 6 decoy RL

2011, Rais Hamidou; 2012, Rais Ali under project 1234EM: - 2 x 2 P20 Termit SSM, Rangout-E, MR-103 Bars radars, 2x PK-16 decoy RL; + 4 x 4 Uran SSM (16 3M24E), Pozitiv-ME1 radar, Laska-E, SP-521 Rakurs e/o systems, 2x 6 decoy RL

Naval service

No significant events.
