TISA midget submarines (1983-1987)
Soča 2000
Ships
| Names | Builders | Completed | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
П911 Тиса [P911 Tisa] П912 Уна [P912 Una] П913 Соча [P914 Soča] П914 Зета [P913 Zeta] П915 Вардар [P915 Vardar] П916 Купа [P916 Kupa] |
BSO Split: P911-916 |
1983: P911 1984: P912 1985: P914, 915 1986: P916 1987: P913 |
P914 Zeta (captured by Croatia 1991 (Velebit)) |
none |
1997: P911, 912 2003: P915 2005: P913, 916 |
Technical data
| Displacement standard, t | |
|---|---|
| Displacement normal, t | 76 / 88 |
| Length, m | 16.5 wl 18.8 oa |
| Breadth, m | 3.00 |
| Draught, m | 2.50 |
| No of shafts | 1 |
| Machinery | 2 electric motors |
| Power, h. p. | 49 |
| Max speed, kts | 8 / 11 |
| Fuel, t | batteries only |
| Endurance, nm(kts) | / 250(3) |
| Armament | 6 mines or 4 R1 swimmer delivery vehicles |
| Complement | 4 + 6 swimmers |
| Diving depth operational, m | 105 |
Standard scale images
Una 1990
Graphics
Soča 2000
Project history
Yugoslavian design, M-100D type. Fitted with exit/re-entry chambers for swimmers. Designed to defend approaches to small shallow waters harbours.
Modernizations
None.
Naval service
No significant events.
