HOME
FIGHTING SHIPS OF THE WORLD
YEMEN, SOUTH / YEMEN
COASTAL FORCES
No 126 fast attack craft (missile) (1995)
No 126 1995
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| 126 | Jiangnan SY, China | 6.6.1995 | in service (2020) | ||||
| 127 | Jiangnan SY, China | 6.6.1995 | in service (2020) | ||||
| 128 | Jiangnan SY, China | 6.6.1995 | in service (2020) |
Technical data
| Displacement standard, t | 175 |
|---|---|
| Displacement full, t | 210 |
| Length, m | 39.0 |
| Breadth, m | 7.70 |
| Draught, m | 1.80 full load |
| No of shafts | 3 |
| Machinery | 3 type 42-160 diesels |
| Power, h. p. | 12000 |
| Max speed, kts | 36 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 800(30) |
| Armament | 4 x 1 C-801 SSM (4 C-801), 1 x 2 QW-1 SAM (4 QW-1), 2 x 2 - 30/71 type 69 |
| Electronic equipment | type 352C, type 347G radars |
| Complement | 30 |
Standard scale images
No 126 1995
Graphics
No 1017 2009
No 126 1995
Project history
Chinese-built type 021 FACs. First was completed in 1993, but delivery was delayed by the the Yemeni civil war.
Modernizations
2002, may be all: - 4 x 1 C-801 SSM
Naval service
All were presumably renumbered. One craft (former 128) ran aground in September 1997 but was salvaged. May be all are in poor condition and not armed with missiles today.
