YP683 2000

Ships

No	Name	Yard No	Builder	Laid down	Launched	Comm	Fate
YP676			Peterson Builders, Sturgeon Bay	7.4.1983	9.4.1984	14.11.1984	stricken 12.2018
YP677			Peterson Builders, Sturgeon Bay	10.10.1983	23.6.1984	5.12.1984	stricken 10.2013
YP678			Peterson Builders, Sturgeon Bay	15.12.1983	3.11.1984	13.5.1985	stricken 11.1998
YP679			Peterson Builders, Sturgeon Bay	18.4.1984	11.12.1984	6.6.1985	auxiliary IX531 8.2001
YP680			Peterson Builders, Sturgeon Bay	2.7.1984	23.3.1985	8.8.1985	stricken 10.2013
YP681			Peterson Builders, Sturgeon Bay	29.10.1984	1.6.1985	30.9.1985	stricken 12.2018
YP682			Peterson Builders, Sturgeon Bay	7.1.1985	3.8.1985	18.11.1985	stricken 10.2013
YP683			Marinette SB	23.7.1985	19.6.1986	13.10.1986	in service (2020)
YP684			Marinette SB	29.8.1985	14.8.1986	10.12.1986	in service (2020)
YP685			Marinette SB	8.10.1985	25.9.1986	23.11.1986	stricken 8.2012
YP686			Marinette SB	23.1.1986	25.10.1986	12.1986	in service (2020)
YP687			Marinette SB	27.2.1986	3.1987	7.3.1987	stricken 12.2018
YP688			Marinette SB	7.4.1986	13.3.1987	22.5.1987	in service (2020)
YP689			Marinette SB	15.7.1986	5.1987	10.6.1987	in service (2020)
YP690			Marinette SB	18.8.1986	4.1987	10.6.1987	in service (2020)
YP691			Marinette SB	28.10.1986	5.1987	7.1987	in service (2020)
YP692			Marinette SB	10.12.1986	18.6.1987	27.7.1987	in service (2020)
YP693			Marinette SB	26.1.1987	14.8.1987	22.9.1987	stricken 3.2001
YP694			Marinette SB	25.2.1987	21.9.1987	27.10.1987	in service (2020)
YP695			Marinette SB	24.3.1987	26.10.1987	1.12.1987	in service (2020)
YP696			Marinette SB	23.4.1987	1988	10.5.1988	stricken 9.2011
YP697			Marinette SB	26.5.1987	1.2.1988	26.5.1988	stricken 10.2014
YP698			Marinette SB	22.6.1987	29.3.1988	16.6.1988	in service (2020)
YP699			Marinette SB	17.8.1987	11.4.1988	30.6.1988	stricken 3.2001
YP700			Marinette SB	22.9.1987	12.5.1988	21.7.1988	in service (2020)
YP701			Marinette SB	28.10.1987	14.6.1988	9.8.1988	in service (2020)
YP702			Marinette SB	10.12.1987	19.7.1988	2.9.1988	stricken 7.2010

Technical data

Displacement standard, t	160
Displacement full, t	175
Length, m	31.0 pp 32.9 oa
Breadth, m	7.39
Draught, m	1.83
No of shafts	2
Machinery	2 General Motors Detroit Diesel 12V-71N diesels
Power, h. p.	874
Max speed, kts	13
Fuel, t	diesel oil 24
Endurance, nm(kts)	1500(12)
Armament	small arms
Electronic equipment	SPS-64(v)9 radar
Complement	30

Graphics

Project history

These wooden-construction boats are used mainly for training and are assigned to Annapolis Naval Academy except YP696, 697, 701 and 702. Wooden hull, Aluminium superstructure.

Modernizations

None.

Fate Notes

No significant events.
