LD42 landing craft (1978)
42 2013
Ships
| Names | Builders | Commissioned | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
LD42 |
Dieque Nacional, Montevideo: LD42 | 1978: LD42 |
none |
none |
in service (2019): LD42 |
Technical data
| Displacement standard, t | 15 |
|---|---|
| Displacement full, t | 31 |
| Length, m | 14.1 |
| Breadth, m | 3.50 |
| Draught, m | 0.80 |
| No of shafts | 2 |
| Machinery | 2 General Motors Detroit Diesel 6-71 diesels |
| Power, h. p. | 272 |
| Max speed, kts | 9 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 580(9) |
| Armament | none |
| Military load | 10 t cargo |
| Complement | 5 |
Graphics
42 2013
Project history
Landing craft, mechanized.
Modernizations
None.
Naval service
None.
