ex-Iranian gunboats (HIRA) (4, 1931 / 1941)





Karkass

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Hira (RIM) (ex-Chahbaaz)     OCP, Naples, Italy   12.9.1931 1931 // 8.1941 to Iran 1946 (شَهباز [Shahbaz])
Lal (RIM) (ex-Simorgh)     CNR, Palermo, Italy   3.8.1931 1931 // 8.1941 to Iran 1946 (سیمرغ [Simurgh])
Moti (RIM) (ex-Karkass)     CNR, Palermo, Italy   24.8.1931 1931 // 8.1941 to Iran 1946 (كركس [Karkass])
Nilam (RIM) (ex-Chahrokh)     CNR, Palermo, Italy   26.7.1931 1931 // 8.1941 to Iran 1946 (شاهرخ [Shahrokh])


Technical data


Displacement standard, t

331

Displacement full, t
Length, m

51.8 pp

Breadth, m

6.70

Draught, m

1.83

No of shafts

2

Machinery

2 Fiat diesels

Power, h. p.

900

Max speed, kts

15.5

Fuel, t

diesel oil

Endurance, nm(kts)
Armament

1 x 1 - 76/40 12pdr 12cwt QF Mk I/II/V, 1 x 1 - 20/70 Oerlikon Mk II/IV

Complement


Standard scale images


<i>Hira </i>1941
Hira 1941


Graphics


<i>Karkass</i>
Karkass


Project history

Iranian gunboats captured by British troops 25.8.1941, used as training and patrol ships at Bombay.

Modernizations

None

1/1946: 1 x 1 - 76/40 P Mk V, 1 x 1 - 20/70 Mk III

Naval service

No significant events.
