NAVYPEDIA


Kingfisher 1980

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Redpole (ex-Sea Otter)	P259		Fairmile, Berwick			4.8.1967 // 30.10.1984	deleted 1994
Kingfisher	P260		Richard Dunston, Hessle	7.1973	20.9.1974	8.10.1975	deleted 1994
Cygnet	P261		Richard Dunston, Hessle	10.1973	26.10.1975	8.7.1976	deleted 1994
Peterel	P262		Richard Dunston, Hessle	11.1973	14.5.1976	7.7.1977	stricken 12.1990
Sandpiper	P263		Richard Dunston, Hessle	12.1973	20.1.1977	16.9.1977	stricken 12.1990

100 - 1000 t displacement/ BRT tonnage vessels

Name No Yard No Builder Laid down Launched Comp Fate Redpole (ex-Sea Otter) P259   Fairmile, Berwick     4.8.1967 // 30.10.1984 deleted 1994 Kingfisher P260   Richard Dunston, Hessle 7.1973 20.9.1974 8.10.1975 deleted 1994 Cygnet P261   Richard Dunston, Hessle 10.1973 26.10.1975 8.7.1976 deleted 1994 Peterel P262   Richard Dunston, Hessle 11.1973 14.5.1976 7.7.1977 stricken 12.1990 Sandpiper P263   Richard Dunston, Hessle 12.1973 20.1.1977 16.9.1977 stricken 12.1990

Technical data

Displacement standard, t	167
Displacement full, t	187
Length, m	36.6 oa 33.8 pp
Breadth, m	7.16
Draught, m	2.00
No of shafts	2
Machinery	2 Paxman 16YJCM diesels
Power, h. p.	4000
Max speed, kts	25
Fuel, t	diesel oil
Endurance, nm(kts)	2000(14)
Armament	1 x 1 - 40/60 Mk 9, 2 x 1 - 7.6/90
Electronic equipment	type 1006(4) radar
Complement	14

Standard scale images

Graphics

Project history

An unsuccessful attempt to adapt an RAF air-sea rescue design, the Seal type, these craft have proved unstable and suffer badly from vibration. Following problems with Kingfisher, the later craft were given a lighter mast and had no scuttles. Redpole was completed as RAF SAR craft Sea Otter and transferred to RN in 1984.

Modernizations

late 1980s, Redpole, Kingfisher, Cygnet: - 1 x 1 - 40/60

Naval service

Peterel and Sandpiper were immediately relegated to RNR training tenders and P259-261 were disarmed for service as inshore surveying craft.
