Abu Dhabi 2013

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
أبو ظبي [Abu Dhabi]	P191		Fincantieri, Riva Trigoso/Muggiano, Italy	2009	15.2.2011	8.1.2013	in service (2020)

Technical data

Displacement standard, t
Displacement full, t	1650
Length, m	80.0 pp 88.4 oa
Breadth, m	12.2
Draught, m	3.30
No of shafts	2
Machinery	2 diesels
Power, h. p.	19040
Max speed, kts	25
Fuel, t	diesel oil
Endurance, nm(kts)	3000(14)
Armament	2 x 4 MM40 Exocet SSM (8 MM40 Block III), 1 x 1 - 76/62 OTO-Melara Compact SR, 2 x 1 - 30/82 Marlin, 2 x 1 - 12.7/90, 2 x 2 - 324 TT, 1 helicopter (Panther AS-565)
Electronic equipment	Kronos 3D, SIR-M, nav. radars, Medusa Mk 4B, NA-30S e/o systems, Kingclip, Captas Nano sonars, 2x MASS decoy RL, WASS torpedo decoy RL, IPN-S CCS
Complement	71

Standard scale images

Graphics

Project history

Modified Italian Comandante Cigala Fulgosi class. Ordered in 2009 with an option for the second unit. Telescopic helicopter hangar. Volumes are reserved for VL MICA SAM launcher.

Modernizations

None.

Naval service

No significant events.
