Osman Gazi 2007

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Osman Gazi	NL125		Taşkizak NSY, Istanbul	5.7.1989	20.7.1990	27.7.1994	in service (2019)
Orhan Gazi	NL126		Taşkizak NSY, Istanbul	1990	---	---	cancelled 7.1991

Technical data

Displacement standard, t
Displacement full, t	3773
Length, m	95.5 wl 105.0 oa
Breadth, m	16.1
Draught, m	4.80 max
No of shafts	2
Machinery	2 MTU 12V1163 TB73 diesels
Power, h. p.	8800
Max speed, kts	17
Fuel, t	diesel oil
Endurance, nm(kts)	4000(15)
Armament	2 x 2 - 40/70 Bofors 106, 1 x 2 - 35/90 GDM-A, 200 mines, helicopter deck
Military load	4 LCVP, 900 troops, 15 tanks
Electronic equipment	Decca 1226 radar
Complement

Standard scale images

Graphics

Project history

Enlarged version of the Sarucabey with 50% more capacity. Has amphibious warfare command facilities and full NBC protection. Has two mineports in the stern, minerails are on the tank deck.

Modernizations

2011: - 2 x 2 - 40/70, Decca 1226 radar; + 1 x 2 - 35/90 GDM-A, 1 x 6 - 20/76 Phalanx Mk 15, 2 x 1 - 20/70 Mk 10, Rascar 2500C, SPS-55, Mk 90 radars, SLQ-32(v)2 ECM suite, 2x SRBOC Mk 36 decoy RL

Naval service

No significant events.
