Heybeliada 2012

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Heybeliada	F511		Istanbul NSY	22.1.2007	27.9.2008	27.9.2011	in service (2019)
Büyükada	F512		Istanbul NSY	28.9.2008	27.9.2011	27.9.2013	in service (2019)
Burgazada	F513		Istanbul NSY	27.9.2013	1.7.2016	4.11.2018	in service (2019)
Kınalıada	F514		Istanbul NSY	18.6.2016	3.7.2017	2019	building (2019)

Technical data

Displacement standard, t	1500
Displacement full, t	2000
Length, m	90.5 pp 99.0 oa
Breadth, m	14.4
Draught, m	3.75
No of shafts	2
Machinery	CODAG: 1 General Electric LM-2500 gas turbine + 2 MTU 16V595 TE90 diesels
Power, h. p.	31280+11750=43030
Max speed, kts	29
Fuel, t	diesel oil
Endurance, nm(kts)	3500(15)
Armament	2 x 4 Harpoon SSM (8 RGM-84L), 1 x 21 RAM SAM (21 RIM-116 Block 1A), 1 x 1 - 76/62 OTO Melara Compact, 2 x 1 - 12.7/90, 2 x 2 - 324 Mk 32 Mod.9 TT (Mk 54), 1 helicopter (S-70B-2)
Electronic equipment	SMART-S Mk 2, Scout Mk 2, Sting EO Mk 2, 2x Sperry Vision Master radars, AselFLIR 300D e/o system, sonar, Ares-2N ES ECM suite, 2x type 2170 Sea Sentor SSTD torpedo decoy launchers, Genesis CCS
Complement	93

Standard scale images

Graphics

Project history

The MILGEM national corvette program is the first modern warship class to be produced and designed domestically in Turkey. Up to ten units eventually may be built for the Turkish navy. The 12.7mm guns in auto-stabilized Aselsan STAMP mounts are guided via an electro-optic sensor; they can be fired manually or automatically. Twin ASW torpedo tubes appear to have been taken from the retired Knox-class units. The class can achieve 15kts cruising speed on one diesel, 27kts on gas turbine and 30kts at full power with two diesels and the gas turbine. A high level of automation allows for reduced crew size.

Modernizations

None.

Naval service

No significant events.
