Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
No1 - 13 No14, 1932- Mülazim Hayati No15 - 24	Thornycroft, Woolston, UK: No1 - 24	1911: No1, 2, 4 - 10 1914: No11 - 23	never completed: No3, 24 No1 (7.11.1914), No2 (9.11.1914), No4 (2.10.1911), No5 (5.7.1915), No6 (19.11.1914), No8 (24.7.1915), No9 (20.10.1912), No10 (20.10.1912), No12 (21.12.1916), No16 (21.12.1916)	None	1917: No7 1919: No19 1927: No13 1932: No17 1934: No20, 22, 23 1939: No11, 15 1941: No21 1943: No18 1949: Mülazim Hayati

Technical data

Displacement normal, t	12
Displacement full, t	20
Length, m	18.3 pp
Breadth, m	3.30
Draught, m	1.60
No of shafts	1
Machinery	2 Thornycroft paraffin engines
Power, h. p.	70
Max speed, kts	11.9
Fuel, t	paraffin 1.9
Endurance, nm(kts)
Armament	(1 -2) x 1 - 37/37 Vickers-Maxim
Complement	6

Standard scale images

Graphics

Project history

Officially rated as motor gunboats and intended for customs and police services. To the Second World War beginning they had strongly worn engines. In total 24 boats were ordered, 22 were completed.

Modernizations

None.

Naval service

No significant events.
