DUQUE DE TETUÁN floating battery (1874)
Duque de Tetuán
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| Duque de Tetuán | Arsenal de Ferrol | 1874 | 1874 | discarded 1900 |
Technical data
| Displacement normal, t | 703 |
|---|---|
| Displacement full, t | |
| Length, m | 43.0 |
| Breadth, m | 9.50 |
| Draught, m | 2.15 |
| No of shafts | 2 |
| Machinery | |
| Power, h. p. | 190 |
| Max speed, kts | 6 |
| Fuel, t | coal 23 |
| Endurance, nm(kts) | |
| Armour, mm | iron; side: 100, battery: 100 |
| Armament | 1 x 1 - 160/16 Parrot MLR, 4 x 1 - 121/12 SBML |
| Complement | 60 |
Graphics
Duque de Tetuán
Project history
Iron-hulled floating battery.
Ship protection
100mm iron armour protected sides and battery.
Modernizations
None.
Naval service
No significant events.
