"Series XV" submarines (M-200) (project 96) (1943 - 1953)
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| М-200 [M-200], 6.1943- М-200 Месть [M-200 Mest'] | 122 | 196 Yd (Sudomekh Wks), Leningrad // 638 Yd (Stalin Yd), Astrakhan | 3.1940 | 17.7.1941 | 20.3.1943 | collision 12.8.1956 | |
| М-201 [M-201] | 123 | 196 Yd (Sudomekh Wks), Leningrad // 638 Yd (Stalin Yd), Astrakhan | 3.1940 | 17.7.1941 | 16.4.1943 | stricken 12.1955 | |
| М-202 Рыбник Донбасса [M-202 Rybnik Donbassa] | 138 | 196 Yd (Sudomekh Wks), Leningrad // 638 Yd (Stalin Yd), Astrakhan | 5.1940 | 15.7.1941 | 19.2.1944 | to Bulgaria 9.1954 (41 М-1 [M-1]) | |
| М-203 Иркутский Рыбак [M-203 Irkutskiy Rybak] | 139 | 196 Yd (Sudomekh Wks), Leningrad // 638 Yd (Stalin Yd), Astrakhan | 10.1940 | 7.7.1941 | 28.10.1944 | to Bulgaria 9.1954 (42 М-2 [M-2]) | |
| М-204 [M-204] | 140 | 196 Yd (Sudomekh Wks), Leningrad | 10.1940 | 17.7.1946 | 25.6.1947 | to Bulgaria 9.1954 (43 М-3 [M-3]) | |
| М-205 [M-205] | 141 | 196 Yd (Sudomekh Wks), Leningrad | 12.1940 | 10.11.1946 | 22.7.1947 | stricken 4.1958 | |
| М-206 [M-206] | 142 | 196 Yd (Sudomekh Wks), Leningrad | 12.1940 | 26.4.1947 | 30.9.1947 | charging plant 1.1958 | |
| М-207 [M-207] | 147 | 196 Yd (Sudomekh Wks), Leningrad | 7/1941 | --- | --- | cancelled 1941 | |
| М-208 [M-208] | 148 | 196 Yd (Sudomekh Wks), Leningrad | 7/1941 | --- | --- | cancelled 1941 | |
| М-209 [M-209] | 149 | 196 Yd (Sudomekh Wks), Leningrad | 7/1941 | --- | --- | cancelled 1941 | |
| М-214 [M-214] | 113/306 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 402 Yd, Molotovsk | 5.1941 | 24.9.1946 | 14.8.1948 | stricken 2.1959 | |
| М-215 [M-215] | 114/307/289 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 402 Yd, Molotovsk // 196 Yd (Sudomekh Wks), Leningrad | 4.1941 | 22.7.1947 | 31.10.1947 | stricken 2.1960 | |
| М-216 [M-216] | 115/308/290 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 402 Yd, Molotovsk // 196 Yd (Sudomekh Wks), Leningrad | 4.1941 | 26.7.1947 | 5.11.1947 | charging plant 2.1960 | |
| М-217 [M-217] | 116/309 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 402 Yd, Molotovsk // 196 Yd (Sudomekh Wks), Leningrad | 4.1941 | 26.7.1947 | 10.11.1947 | stricken 2.1960 | |
| М-218 [M-218] | 117/310 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 402 Yd, Molotovsk // 196 Yd (Sudomekh Wks), Leningrad | 4.1941 | 10.9.1947 | 10.11.1947 | stricken 2.1960 | |
| М-219 [M-219] | 118/311 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 402 Yd, Molotovsk | 4.1941 | --- | --- | cancelled 7.1946 | |
| М-234 [M-234] | 353 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 196 Yd (Sudomekh Wks), Leningrad | 6.1941 | 25.4.1948 | 31.7.1948 | stricken 4.1958 | |
| М-235 [M-235] | 354 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 196 Yd (Sudomekh Wks), Leningrad | 6.1941 | 25.4.1948 | 25.8.1948 | stricken 2.1960 | |
| М-236 [M-236] | 355 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 196 Yd (Sudomekh Wks), Leningrad | 19.2.1947 | 19.6.1948 | 19.10.1948 | to Poland 4.1954 (M102 Krakowiak) | |
| М-237 [M-237] | 373 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 196 Yd (Sudomekh Wks), Leningrad | 15.3.1947 | 27.7.1948 | 29.11.1948 | charging plant 11.1960 | |
| М-238 [M-238] | 374 | 112 Yd (Krasnoye Sormovo Yd), Gorkiy // 196 Yd (Sudomekh Wks), Leningrad | 25.4.1947 | 21.8.1948 | 7.12.1948 | stricken 2.1960 | |
| М-239 [M-239] | 375 | 196 Yd (Sudomekh Wks), Leningrad | 7.6.1947 | 2.10.1948 | 14.7.1949 | stricken 11.1960 | |
| М-240 [M-240] | 376 | 196 Yd (Sudomekh Wks), Leningrad | 27.8.1948 | 22.11.1948 | 30.7.1949 | stricken 11.1960 | |
| М-241 [M-241] | 377 | 196 Yd (Sudomekh Wks), Leningrad | 31.8.1948 | 30.12.1948 | 30.7.1949 | stricken 4.1958 | |
| М-242 [M-242] | 378 | 196 Yd (Sudomekh Wks), Leningrad | 30.9.1948 | 30.3.1949 | 30.7.1949 | stricken 2.1960 | |
| М-243 [M-243] | 379 | 196 Yd (Sudomekh Wks), Leningrad | 31.10.1948 | 30.4.1949 | 31.8.1949 | charging plant 2.1960 | |
| М-244 [M-244] | 380 | 196 Yd (Sudomekh Wks), Leningrad | 24.11.1948 | 1.6.1949 | 1.10.1949 | charging plant 2.1960 | |
| М-245 [M-245] | 381 | 196 Yd (Sudomekh Wks), Leningrad | 30.11.1948 | 30.6.1949 | 31.10.1949 | to Poland 4.1955 (M104 Kujawiak) | |
| М-246 [M-246] | 382 | 196 Yd (Sudomekh Wks), Leningrad | 25.1.1949 | 24.7.1949 | 16.11.1949 | to Poland 4.1955 (M105 Kurp) | |
| М-247 [M-247] | 383 | 196 Yd (Sudomekh Wks), Leningrad | 14.2.1949 | 31.8.1949 | 22.11.1949 | charging plant 11.1960 | |
| М-248 [M-248] | 384 | 196 Yd (Sudomekh Wks), Leningrad | 24.2.1949 | 26.9.1949 | 23.11.1949 | stricken 2.1960 | |
| М-249 [M-249] | 385 | 196 Yd (Sudomekh Wks), Leningrad | 25.4.1949 | 30.10.1949 | 31.12.1949 | stricken 2.1960 | |
| М-250 [M-250] | 386 | 196 Yd (Sudomekh Wks), Leningrad | 28.6.1949 | 28.11.1949 | 2.6.1950 | stricken 11.1960 | |
| М-251 [M-251] | 387 | 196 Yd (Sudomekh Wks), Leningrad | 23.9.1949 | 22.12.1949 | 25.6.1950 | stricken 2.1960 | |
| М-252 [M-252] | 388 | 196 Yd (Sudomekh Wks), Leningrad | 22.10.1949 | 26.3.1950 | 10.7.1950 | stricken 2.1960 | |
| М-253 [M-253] | 389 | 196 Yd (Sudomekh Wks), Leningrad | 9.11.1949 | 30.3.1950 | 29.7.1950 | stricken 2.1961 | |
| М-270 [M-270] | 500 | 196 Yd (Sudomekh Wks), Leningrad | 23.12.1949 | 24.4.1950 | 29.7.1950 | to Poland 12.1954 (M103 Ślązak) | |
| М-271 [M-271] | 501 | 196 Yd (Sudomekh Wks), Leningrad | 31.1.1950 | 30.4.1950 | 28.8.1950 | to Egypt 6.1957 (name unknown) | |
| М-272 [M-272] | 502 | 196 Yd (Sudomekh Wks), Leningrad | 25.2.1950 | 13.6.1950 | 11.9.1950 | charging plant 11.1960 | |
| М-273 [M-273] | 503 | 196 Yd (Sudomekh Wks), Leningrad | 18.3.1950 | 20.7.1950 | 28.9.1950 | stricken 5.1963 | |
| М-274 [M-274] | 504 | 196 Yd (Sudomekh Wks), Leningrad | 29.4.1950 | 18.9.1950 | 31.10.1950 | to Poland 7.1954 (M101 Mazur) | |
| М-275 [M-275] | 505 | 196 Yd (Sudomekh Wks), Leningrad | 25.5.1950 | 23.9.1950 | 15.11.1950 | stricken 2.1961 | |
| М-276 [M-276] | 506 | 196 Yd (Sudomekh Wks), Leningrad | 28.6.1950 | 17.10.1950 | 25.12.1950 | to China 12.1954 (长城 200 [Changcheng 200]) | |
| М-277 [M-277] | 507 | 196 Yd (Sudomekh Wks), Leningrad | 31.7.1950 | 1950/51 | 24.5.1951 | to China 12.1954 (长城 201 [Changcheng 201]) | |
| М-278 [M-278] | 508 | 196 Yd (Sudomekh Wks), Leningrad | 31.8.1950 | 19.1.1951 | 28.5.1951 | to China 7.1955 (长城 202 [Changcheng 202]) | |
| М-279 [M-279] | 509 | 196 Yd (Sudomekh Wks), Leningrad | 12.10.1950 | 10.2.1951 | 9.6.1951 | to China 7.1955 (长城 203 [Changcheng 203]) | |
| М-280 [M-280] | 510 | 196 Yd (Sudomekh Wks), Leningrad | 20.12.1950 | 14.4.1951 | 21.7.1951 | stricken 2.1961 | |
| М-281 [M-281] | 619 | 196 Yd (Sudomekh Wks), Leningrad | 4.2.1951 | 29.4.1951 | 23.8.1951 | stricken 12.1966 | |
| М-282 [M-282] | 620 | 196 Yd (Sudomekh Wks), Leningrad | 11.3.1951 | 12.6.1951 | 14.9.1951 | stricken 12.1966 | |
| М-283 [M-283] | 621 | 196 Yd (Sudomekh Wks), Leningrad | 2.4.1951 | 3.7.1951 | 30.9.1951 | stricken 1.1963 | |
| М-284 [M-284] | 622 | 196 Yd (Sudomekh Wks), Leningrad | 3.5.1951 | 11.8.1951 | 31.10.1951 | stricken 5.1963 | |
| М-285 [M-285] | 623 | 196 Yd (Sudomekh Wks), Leningrad | 31.5.1951 | 14.9.1951 | 12.2.1952 | stricken 2.1961 | |
| М-286 [M-286] | 624 | 196 Yd (Sudomekh Wks), Leningrad | 29.6.1951 | 15.10.1951 | 25.6.1952 | stricken 2.1961 | |
| М-287 [M-287] | 625 | 196 Yd (Sudomekh Wks), Leningrad | 25.6.1951 | 15.11.1951 | 25.6.1952 | stricken 11.1962 | |
| М-288 [M-288] | 626 | 196 Yd (Sudomekh Wks), Leningrad | 24.8.1951 | 24.1.1952 | 24.7.1952 | stricken 5.1963 | |
| М-289 [M-289] | 627 | 196 Yd (Sudomekh Wks), Leningrad | 27.9.1951 | 28.4.1952 | 27.8.1952 | stricken 5.1963 | |
| М-290 [M-290] | 628 | 196 Yd (Sudomekh Wks), Leningrad | 10.11.1951 | 27.5.1952 | 30.9.1952 | to Poland 7.1954 (M100 Kaszub) | |
| М-291 [M-291] | 629 | 196 Yd (Sudomekh Wks), Leningrad | 28.12.1951 | 1.7.1952 | 25.11.1952 | stricken 11.1960 | |
| М-292 [M-292] | 644 | 196 Yd (Sudomekh Wks), Leningrad | 15.4.1952 | 30.9.1952 | 12.1.1953 | stricken 5.1963 | |
| М-293 [M-293] | 645 | 196 Yd (Sudomekh Wks), Leningrad | 10.2.1952 | 2.10.1952 | 12.1.1953 | stricken 11.1960 | |
| М-294 [M-294] | 646 | 196 Yd (Sudomekh Wks), Leningrad | 29.5.1952 | 22.10.1952 | 26.2.1953 | stricken 11.1960 |
Technical data
| Displacement standard, t |
|
|---|---|
| Displacement normal, t | 280 / 351 |
| Length, m | 49.5 |
| Breadth, m | 4.40 |
| Draught, m | 2.81 |
| No of shafts | 2 |
| Machinery | 2 11D diesels / 2 PG-17 electric motors |
| Power, h. p. | 1200 / 430 |
| Max speed, kts | 15.5 / 7.9 |
| Fuel, t | diesel oil 14 |
| Endurance, nm(kts) | 4500(8) / 85(2.9) |
| Armament | M200-203: 1 x 1 - 45/43 21K, 4 - 533 TT (bow, 4) others: 1 x 1 - 45/46 21K, 4 - 533 TT (bow, 4) |
| Electronic equipment | Mars-8 hydrophone |
| Complement | 23 |
| Diving depth operational, m | 60 |
Standard scale images
M-200 1943
M-291 1959
Graphics
Project history
The basic requirements to small submarine which working out has begun in III five-years period, were installation of the second shaft and increasing twice of a torpedo salvo. Displacement growth on 35% became a payment. The saddle-tank construction with demountable bulges has been applied to preserve of possibility of transportation by rail. The stability was improved, surfaced speed has grown on 1.5kts, and diving depth on 10m. Project of XV series was approved 23.7.1939.
Modernizations
1957, all survived: - 1 x 1 - 45/46.
Naval service
M-200 Mest' collided 12.8.1956 with destroyer Statnyy at Tallin and sunk with all hands, salvaged 21.11.1956 and used as training hulk till 1958.
