Kasatka 1905

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Касатка [Kasatka]			Baltic Wks, St. Petersburg	3.1904	7.7.1904	3.1905	stricken 11.1925
Макрель [Makrel`]			Baltic Wks, St. Petersburg	4.1904	27.8.1904	8.1908	stricken 11.1925
Налим [Nalim]			Baltic Wks, St. Petersburg	4/1904	8.9.1904	5.1905	captured by Germany 1.5.1918
Окунь [Okun`]			Baltic Wks, St. Petersburg	4.1904	13.9.1904	7.1908	stricken 11.1925
Скат [Skat]			Baltic Wks, St. Petersburg	3.1904	3.9.1904	4.1905	captured by Germany 1.5.1918
Фельдмаршал Граф Шереметьев [Feldmarshal Graf Sheremetyev], 8.1917- Кета [Keta]			Baltic Wks, St. Petersburg	spring 1904	21.8.1904	5.1905	foundered 23.9.1924

Technical data

Displacement standard, t
Displacement normal, t	140 - 142 / 177
Length, m	33.4
Breadth, m	3.39
Draught, m	2.80
No of shafts	Kasatka, Nalim, Skat, Feldmarshal Graf Sheremetyev, Okun': 1 Makrel: 3
Machinery	Kasatka, Nalim, Skat, Feldmarshal Graf Sheremetyev, Okun': 2 kerosine dynamo machines, 1 electric motor Makrel: 2 kerosine engines / 1 electric motor
Power, h. p.	Kasatka, Nalim, Skat, Feldmarshal Graf Sheremetyev, Okun': 100 Makrel: 120 / 100
Max speed, kts	Kasatka, Nalim, Skat, Feldmarshal Graf Sheremetyev, Okun': 14 / 8.5 Makrel: 9 / 8.5
Fuel, t	kerosene 4.8
Endurance, nm(kts)	1200(7) / 70(5)
Armament	4 - 450 TT (side drop-collars, 4)
Complement	24
Diving depth operational, m	50 (max)

Standard scale images

Graphics

Project history

Design of I. G. Bubnov. Single-hulled, without watertight bulkheads. Okun ` and Makrel ` under original project should have 3 petrol motors for surface trim, but because of their absence completion was delayed. Finally diesels working with electric motors on one shaft were installed. Kasatka, Nalim, Skat and Graf Sheremetev were completed under original project.

Modernizations

1911, Makrel': 2 shafts were removed, new power plant consisted of 1 diesel / 1 electric motor (120 / 100hp, 9.5kts, 2.6t of diesel oil), large bridge amidships was fitted.

1911, Okun': kerosine dynamo machines were replaced by 1 diesel (120/100hp)

1910s, Kasatka, Feldmarshal Graf Sheremetyev: + 1 x 1 - 7.6/94

1915, Nalim, Skat: + 1 x 1 - 47/40 Hotchkiss

Naval service

Skat and Nalim were scuttled by British-French troops off Sevastopol. Nalim was raised in 1932 and broken up. Keta 23.9.1924 was foundered by flood at Kronshtadt, later wreck was raised and broken up.
