YORSH gunboat (1875)
Yorsh
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| Ёрш [Yorsh] | New Admiralty, St. Petersburg | 10.1873 | 17.8.1874 | 1875 | stricken 8.1907 |
Technical data
| Displacement normal, t | 321 |
|---|---|
| Displacement full, t | |
| Length, m | 29.6 wl 30.1 oa |
| Breadth, m | 8.69 |
| Draught, m | 2.23 max |
| No of shafts | 2 |
| Machinery | 2 HC, 2 cylindrical boilers |
| Power, h. p. | 240 |
| Max speed, kts | 8 |
| Fuel, t | coal |
| Endurance, nm(kts) | |
| Armament | 1 x 1 - 279/17 obr. 1867 |
| Complement | 44 |
Standard scale images
Yorsh 1875
Graphics
Yorsh
Project history
Composite-hulled, with the 279mm mounted as a pivot gun on a descending platform and training 12° each side of the keel line by means of a steam capstan.
Modernizations
1879: + 2 x 1 - 44/41 Ängström
1900: armament consisted of 4 x 1 - 87/21 4pdr obr. 1877
Naval service
No significant events.
