Berdyansk Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Бердянск [Berdyansk] (ex-Ardeal, ex-Drina, ex-Temes)		902	Danubius Schönichen, Ujpest, Austria-Hungary	1.1903	26.3.1904	5.1905 // 11.1944	to Romania 7.1951 (M207)

Technical data

Displacement standard, t	450
Displacement full, t	650
Length, m	59.0
Breadth, m	9.5
Draught, m	1.60
No of shafts	2
Machinery	2 VTE, 2 Yarrow boilers
Power, h. p.	1400
Max speed, kts	10
Fuel, t	coal 62
Endurance, nm(kts)	500(8)
Armour, mm	belt: 70, deck: 70 - 45, turrets: 50, CT: 75
Armament	3 x 1 - 120/50 Škoda-Bofors Mk 4, 4 x 1 - 37/63 70K, 4 x 1 - 20/70 Oerlikon Mk IV
Complement	129

Standard scale images

Graphics

Project history

Former Romanian monitors, captured by Soviet troops on Danube 6-29.8.1944 and 10.11.1944 commissioned by Danube Flotilla.

Ship protection

Deck had 45mm thickness increasing to 70mm over machinery.

Modernizations

None.

Naval service

28.2.1948 all were laid up and 3.7.1951 returned to Romania.
