ISKRA port vessels (1914)





Patron 1914 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Искра [Iskra]   558 Smiths Dock, South Bank, UK 12.1912 3.9.1913 2.1914 sunk 6.10.1916
Пламя [Plamia], 8.1933- T-33, 11.1939- T-891 17 559 Smiths Dock, South Bank, UK 12.1912 17.9.1913 2.1914 captured by Finland 4.1918, returned 9.1922, board guard ship 10.1922, stricken 4.1924, minesweeper 8.1933, stricken 4.1947
Патрон [Patron], 8.1933- T-31, 11.1939- T-890 18 560 Smiths Dock, South Bank, UK 12.1912 17.9.1913 2.1914 guard ship 8.1918, stricken 5.1921, minesweeper 8.1933, sunk 9.7.1941


Technical data


Displacement normal, t420
Displacement full, t
Length, m

44.5

Breadth, m

7.47

Draught, m

3.28

No of shafts

1

Machinery

1 VTE, 1 water-tube boiler

Power, h. p.

650

Max speed, kts

11.6

Fuel, t

coal 100

Endurance, nm(kts)1400(9.5)
Armament

2 x 1 - 75/48 Canet, mechanical minesweeping gear, 45 mines

Complement49


Standard scale images


<i>Iskra</i> 1914
Iskra 1914


Graphics


<i>Patron</i> 1914 <i>Many thanks to Wolfgang Stöhr for additional information on this page.</i>
Patron 1914 Many thanks to Wolfgang Stöhr for additional information on this page.


Project history

Built on the basis of trawler hull. Intended for Siberian Flotilla, but because of beginning of war remained on Baltic.

Modernizations

1933, T-31, T-33: were armed with 1 x 1 - 76/28 8K, 1 x 1 - 45/43 21K, 2 x 1 - 7.6/94, mechanical minesweeping gear

1943, T-891: - 1 x 1 - 76/28, 2 x 1 - 7.6/94; + 1 x 1 - 37/63 70K, 2 x 1 - 12.7/79

Naval service

Iskra was lost 6.10.1916 on a mine, remaining two in  In 1923-1924 they were disarmed, converted to trawlers and renamed RT-33 Nalim and RT-35 Forel. 9.8.1933 they were again converted to minesweepers and commissioned by Northern Fleet as T-31 and 33 respectively.    T-890 was sunk 9.7.1941 by German aircraft in Zapadnaya Litsa Bay.

Many thanks to Wolfgang Stöhr for additional information on this page.
