NAVYPEDIA


No23

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
№11 [No11] №12 [No12], 6.1944- KT-653 №13 [No13] №14 [No14] №15 [No15], 6.1944- КЭМТЩ-511 [KEMTShch-511] №21 [No21], 10.1945- KT-894 №22 [No22], 6.1944- KT-654 №23 - 25 [No23 - 25] №31 [No31] №32 [No32], 6.1944- KT-655 №33 - 35 [No33 - 35] №41 [No41] №42 [No42] №43 [No43], 6.1944- КЭМТЩ-512 [KEMTShch-512] №44 [No44], 10.1945- KT-895 №45 [No45] №51 [No51], 10.1945- KT-896 №52 [No52], 6.1944- КЭМТЩ-513 [KEMTShch-513] №53 - 55 [No53 - 55] №61 [No61] №62 [No62], 6.1944- КЭМТЩ-514 [KEMTShch-514] №63 [No63], 10.1945- KT-897 №64 [No64], 6.1944- КЭМТЩ-515 [KEMTShch-515] №65 [No65] №71 [No71] №72 [No72], 6.1944- KT-656 №73 - 75 [No73 - 75] №81 [No81] №82 [No82], 6.1944- КЭМТЩ-516 [KEMTShch-516] №83 [No83] №84 [No84] №85 [No85], 10.1945- KT-891 №91 [No91], 6.1944- КЭМТЩ-820 [KEMTShch-820] №92 [No92], 6.1944- KT-657 №93 [No93] №94 [No94], 10.1945- KT-893 №95 [No95], spring 1945- KT-858 №101 [No101] №102 [No102], 6.1944- КЭМТЩ-518 [KEMTShch-518] №103 - 105 [No103 - 105]	189 Yd, Leningrad; 190 Yd, Leningrad; 194 Yd, Leningrad; 363 Yd, Leningrad; 370 Yd, Leningrad: No11-15, 21-25, 31-35, 41-45, 51-55, 61-65, 71-75, 81-85, 91-95, 101-105	1942: No11 - 15, 21 - 25, 31 - 35, 41 - 45, 51 - 55, 61 - 65, 71 - 75, 81 - 85, 91 - 95, 101 - 105	No11 (12.2.1944), No14 (11/1943), No25 (8.11.1943), No31 (22.1.1944), No34 (20.1.1944), No35 (10.12.1943), No41 (25.4.1944), No42 (20.4.1944), No45 (23.1.1944), No55 (30.7.1942), No65 (7.11.1943), No71 (30.7.1942), No75 (30.7.1942), No83 (30.7.1942), No103 (20.11.1943), No105 (30.7.1942)	none	1943: No81 1945: No13, KEMTShch-511, No24, KEMTShch-512, 513, No53, 61, KEMTShch-514, 515, No73, 74, KEMTShch-516, No84, KT-891, KEMTShch-820, No93, KT-858, No101, KEMTShch-518 late 1940s: KT-653, 894, 654, No23, KT-655, No33, KT-895, 896, No54, KT-897, 656, 657, 893, No104

Technical data

Displacement standard, t
Displacement full, t	26
Length, m	10.3
Breadth, m	3.30
Draught, m	1.10
No of shafts	1
Machinery	1 petrol engine
Power, h. p.	73
Max speed, kts	6
Fuel, t	petrol
Endurance, nm(kts)	75(5)
Armament	1 x 1 - 12.7/79
Military load	70 men or 12 t of cargo
Complement	5

Standard scale images

Graphics

Project history

Built under the decision of the War council of Leningrad front from 7.5.1942 for service on Ladoga on the "Road of Life": providing of beleaguered Leningrad by foodstuffs and ammunition and evacuation of citizens. They had strongly pronounced lines of an impromptu of a wartime: so, tender hull was welded from several flat sheets and shared on some sections. They were built in Leningrad in three variants: one-hold (12t capacity), small and big two-holds (15 and 25t capacity). They were originally used as cargo vessels on Ladoga, since 1943 as landing ships on Baltic and Black Sea. In 1944 22 boats were converted to minesweeping boats.

Modernizations

1944, KT-653 - 657; 1945, KT-858, 891, 893, 894 - 897: - military load capacity; + mechanical minesweeping gear.

1944, KEMTShch-511 - 516, 518, 820: - military load capacity; + magnetic minesweeping gear.

Naval service

No significant events.
