MPK-192 small ASW ships (project 1331M) (1986 - 1990)
Bashkortostan 2002
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| МПК-192 [MPK-192], 1.2011- Уренгой [Urengoy] | 304 | 373 | Peenewerft, Wolgast, East Germany | 26.2.1985 | 29.8.1985 | 19.12.1986 | in service (2019) |
| МПК-205 [MPK-205], 2.1998- Казанец [Kazanets] | 311 | 374 | Peenewerft, Wolgast, East Germany | 4.1.1985 | 28.12.1985 | 28.4.1986 | in service (2019) |
| МПК-67 [MPK-67] | 375 | Peenewerft, Wolgast, East Germany | 28.3.1985 | 19.4.1986 | 30.6.1987 | stricken 6.2005 | |
| МПК-99 [MPK-99], 10.2004- Зеленодольск [Zelenodolsk] | 308 | 376 | Peenewerft, Wolgast, East Germany | 25.6.1985 | 12.8.1986 | 28.12.1987 | in service (2019) |
| МПК-105 [MPK-105] | 377 | Peenewerft, Wolgast, East Germany | 30.12.1985 | 20.11.1986 | 16.3.1988 | stricken 2014 | |
| МПК-213 [MPK-213] | 378 | Peenewerft, Wolgast, East Germany | 8.4.1986 | 28.2.1987 | 29.7.1988 | stricken 5.2004 | |
| МПК-216 [MPK-216] | 379 | Peenewerft, Wolgast, East Germany | 22.6.1986 | 25.6.1987 | 30.9.1988 | stricken 6.2005 | |
| МПК-219 [MPK-219] | 380 | Peenewerft, Wolgast, East Germany | 7.11.1986 | 30.9.1987 | 23.12.1988 | stricken 4.2002 | |
| МПК-224 [MPK-224], 3.2005- Алексин [Aleksin] | 318 | 381 | Peenewerft, Wolgast, East Germany | 28.2.1987 | 30.3.1988 | 31.3.1989 | in service (2019) |
| МПК-227 [MPK-227], 5.2015- Кабардино-Балкария [Kabardino-Balkariya] | 322 | 382 | Peenewerft, Wolgast, East Germany | 2.9.1987 | 16.8.1988 | 29.6.1989 | in service (2019) |
| МПК-228 [MPK-228], 9.1999- Башкортостан [Bashkortostan] | 383 | Peenewerft, Wolgast, East Germany | 20.11.1987 | 31.10.1988 | 26.9.1989 | stricken 2010 | |
| МПК-229 [MPK-229], 4.1996- Калмыкия [Kalmykiya] | 232 | 384 | Peenewerft, Wolgast, East Germany | 23.2.1988 | 30.1.1989 | 6.4.1990 | in service (2019) |
Technical data
| Displacement standard, t | 865 |
|---|---|
| Displacement normal, t | 935 |
| Length, m | 75.2 |
| Breadth, m | 9.78 |
| Draught, m | 2.65 hull 4.40 max |
| No of shafts | 3 |
| Machinery | 3 M-504A diesels |
| Power, h. p. | 14250 |
| Max speed, kts | 24.5 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 2500(12) |
| Armament | 2 x 4 Strela-2M or Strela-3 SAM (16 9M32M or 9M36), 1 x 1 - 76/59 AK-176M, 1 x 6 - 30/54 AK-630M, 2 x 2 - 533 TT, 2 x 12 RBU-6000 Smerch-2 ASWRL, 2 DCR (20) |
| Electronic equipment | MR-352 Pozitiv, MR-123 Vympel radars, MGK-335MS Platina-MS, MG-349M Uzh sonars |
| Complement | 80 |
Standard scale images
MPK-192 1990
Graphics
Bashkortostan 2002
Project history
Soviet version of a standard East German type, equipped with a belter air search radar and better weapons. The dipping sonar deploys through a door on the starboard side of the main deck superstructure.
Modernizations
None.
Naval service
No significant events.
