MPK-15 small ASW ships (project 204) (1960 - 1968)





Project 204

Ships


Name No Yard No Builder Laid down Launched Comp Fate Modification
МПК-15 [MPK-15]   801 Zaliv, Kerch' 26.11.1958 30.3.1960 29.12.1960 TS 6.1979, stricken 5.1984 Project 204
МПК-16 [MPK-16]   802 Zaliv, Kerch' 17.1.1959 27.7.1960 31.12.1960 stricken 5.1981 Project 204
МПК-72 [MPK-72]   803 Zaliv, Kerch' 12.8.1959 30.12.1960 30.9.1962 stricken 4.1990 Project 204
МПК-75 [MPK-75]   804 Zaliv, Kerch' 18.10.1959 29.4.1961 26.10.1962 stricken 6.1988 Project 204
МПК-88 [MPK-88]   805 Zaliv, Kerch' 22.3.1960 25.8.1961 19.11.1962 stricken 6.1985 Project 204
МПК-148 [MPK-148]   806 Zaliv, Kerch' 22.7.1960 18.1.1962 28.12.1962 to Bulgaria 3.1983 (ПЛК-43 [PLK-43]) Project 204
МПК-58 [MPK-58]   807 Zaliv, Kerch' 10.2.1961 29.4.1962 31.7.1963 stricken 10.1987 Project 204
МПК-77 [MPK-77]   808 Zaliv, Kerch' 3.6.1961 13.10.1962 30.9.1963 to Bulgaria 4.1982 (ПЛК-41 [PLK-41]) Project 204
МПК-85 [MPK-85]   809 Zaliv, Kerch' 7.7.1961 22.4.1963 29.12.1963 stricken 6.1987 Project 204
МПК-14 [MPK-14]   810 Zaliv, Kerch' 3.10.1961 25.9.1963 31.12.1963 stricken 6.1987 Project 204
МПК-10 [MPK-10]   811 Zaliv, Kerch' 23.6.1962 30.1.1964 30.6.1964 stricken 5.1989 Project 204
МПК-62 [MPK-62]   812 Zaliv, Kerch' 19.2.1964 3.9.1964 20.10.1964 test vessel OS-573 7.1986, stricken 7.1989 Project 204
МПК-68 [MPK-68]   813 Zaliv, Kerch' 8.8.1962 23.9.1964 30.12.1964 stricken 4.1990 Project 204
МПК-38 [MPK-38]   814 Zaliv, Kerch' 29.7.1963 28.12.1964 31.5.1965 stricken 4.1990 Project 204
МПК-19 [MPK-19]   815 Zaliv, Kerch' 31.12.1964 23.7.1965 28.12.1965 stricken 4.1990 Project 204
МПК-59 [MPK-59]   816 Zaliv, Kerch' 12.3.1965 30.12.1965 28.3.1966 to Bulgaria 6.1975 (ПЛК-33 [PLK-33]) Project 204
МПК-100 [MPK-100]   817 Zaliv, Kerch' 9.7.1965 28.4.1966 5.9.1966 stricken 4.1990 Project 204
МПК-109 [MPK-109]   818 Zaliv, Kerch' 4.11.1965 26.8.1966 27.12.1966 to Bulgaria 11.1982 (ПЛК-42 [PLK-42]) Project 204
МПК-106 [MPK-106]   819 Zaliv, Kerch' 30.8.1966 21.3.1967 30.6.1967 to Bulgaria 8.1975 (ПЛК-34 [PLK-34] or ПЛК-35 [PLK-35]) Project 204
МПК-125 [MPK-125]   820 Zaliv, Kerch' 28.2.1967 29.6.1967 30.9.1967 to Bulgaria 8.1975 (ПЛК-34 [PLK-34] or ПЛК-35 [PLK-35]) Project 204
МПК-128 [MPK-128]   821 Zaliv, Kerch' 18.9.1967 10.1.1968 30.4.1968 stricken 6.1991 Project 204
МПК-56 [MPK-56]   101 Krasny Metallist, Zelenodolsk 23.10.1959 7.4.1961 31.7.1963 stricken 6.1979 Project 204
МПК-79 [MPK-79]   102 Krasny Metallist, Zelenodolsk 19.8.1960 7.6.1961 31.12.1962 stricken 5.1989 Project 204
МПК-84 [MPK-84]   103 Krasny Metallist, Zelenodolsk 20.8.1960 23.8.1961 22.9.1963 target 5.1980 Project 204
МПК-150 [MPK-150]   104 Krasny Metallist, Zelenodolsk 22.7.1960 6.9.1961 20.6.1963 stricken 7.1986 Project 204
МПК-166 [MPK-166]   105 Krasny Metallist, Zelenodolsk 21.3.1961 4.12.1961 20.6.1963 stricken 5.1989 Project 204
МПК-156 [MPK-156]   106 Krasny Metallist, Zelenodolsk 12.6.1961 25.4.1962 30.11.1963 stricken 5.1984 Project 204
МПК-13 [MPK-13]   107 Krasny Metallist, Zelenodolsk 30.8.1961 4.7.1962 22.12.1963 stricken 6.1985 Project 204
МПК-45 [MPK-45]   108 Krasny Metallist, Zelenodolsk 18.11.1961 6.8.1962 31.12.1963 stricken 4.1990 Project 204
МПК-50 [MPK-50]   109 Krasny Metallist, Zelenodolsk 9.11.1961 9.11.1962 30.12.1963 stricken 4.1990 Project 204
МПК-55 [MPK-55]   110 Krasny Metallist, Zelenodolsk 18.2.1962 28.10.1962 30.6.1964 stricken 6.1991 Project 204
МПК-70 [MPK-70]   111 Krasny Metallist, Zelenodolsk 3/1962 late 1963 autumn 1964 stricken 5.1989 Project 204
МПК-63 [MPK-63]   112 Krasny Metallist, Zelenodolsk 11.4.1962 15.8.1963 30.8.1964 stricken 6.1988 Project 204
МПК-21 [MPK-21]   113 Krasny Metallist, Zelenodolsk 8.8.1962 12.6.1963 15.12.1964 stricken 6.1987 Project 204
МПК-23 [MPK-23]   114 Krasny Metallist, Zelenodolsk 15.10.1962 23.7.1963 23.12.1964 stricken 8.1989 Project 204
МПК-27 [MPK-27]   115 Krasny Metallist, Zelenodolsk 22.2.1963 5.11.1963 30.6.1965 stricken 5.1989 Project 204
МПК-25 [MPK-25]   116 Krasny Metallist, Zelenodolsk 23.2.1963 30.4.1964 28.9.1965 stricken 4.1990 Project 204
МПК-29 [MPK-29]   117 Krasny Metallist, Zelenodolsk 16.5.1963 3.6.1964 30.9.1965 stricken 4.1990 Project 204
МПК-18 [MPK-18]   118 Krasny Metallist, Zelenodolsk 27.7.1963 2.9.1964 16.12.1965 stricken 6.1987 Project 204
МПК-54 [MPK-54]   119 Krasny Metallist, Zelenodolsk 6.11.1963 17.11.1964 24.12.1965 stricken 6.1988 Project 204
МПК-74 [MPK-74]   120 Krasny Metallist, Zelenodolsk 13.1.1964 2.6.1965 30.6.1966 stricken 6.1991 Project 204
МПК-80 [MPK-80]   121 Krasny Metallist, Zelenodolsk 23.3.1964 5.7.1965 10.8.1966 stricken 5.1989 Project 204
МПК-86 [MPK-86]   122 Krasny Metallist, Zelenodolsk 15.6.1964 19.7.1965 27.9.1967 stricken 6.1987 Project 204
МПК-90 [MPK-90]   123 Krasny Metallist, Zelenodolsk 21.9.1964 18.11.1965 26.11.1966 stricken 7.1986 Project 204
МПК-92 [MPK-92]   124 Krasny Metallist, Zelenodolsk 8.7.1965 24.5.1966 24.12.1966 stricken 4.1990 Project 204
МПК-95 [MPK-95]   125 Krasny Metallist, Zelenodolsk autumn 1965 early 1966 29.6.1967 stricken 6.1988 Project 204
МПК-97 [MPK-97]   126 Krasny Metallist, Zelenodolsk 1.3.1966 17.9.1966 31.8.1967 stricken 4.1990 Project 204
МПК-83 [MPK-83]   127 Krasny Metallist, Zelenodolsk 5.5.1966 2.11.1966 30.9.1967 stricken 7.1991 Project 204
МПК-94 [MPK-94]   128 Krasny Metallist, Zelenodolsk 12.7.1966 29.1.1967 30.11.1967 stricken 4.1990 Project 204
МПК-98 [MPK-98]   129 Krasny Metallist, Zelenodolsk 21.9.1966 6.5.1967 25.12.1967 stricken 6.1988 Project 204
МПК-102 [MPK-102]   130 Krasny Metallist, Zelenodolsk 11.11.1966 30.6.1967 30.6.1968 stricken 6.1991 Project 204
МПК-119 [MPK-119]   131 Krasny Metallist, Zelenodolsk 20.3.1967 5.11.1967 25.9.1968 stricken 6.1991 Project 204
МПК-169 [MPK-169]   501 Khabarovsk SYd 16.4.1960 15.10.1961 31.12.1962 stricken 5.1980 Project 204
МПК-103 [MPK-103]   502 Khabarovsk SYd 3.3.1961 29.9.1962 31.12.1963 stricken 7.1982 Project 204
МПК-107 [MPK-107]   503 Khabarovsk SYd 31.7.1961 25.5.1963 28.12.1963 target 6.1983 Project 204
МПК-1 [MPK-1]   504 Khabarovsk SYd 15.12.1961 29.7.1963 27.10.1964 stricken 5.1984 Project 204
МПК-17 [MPK-17]   505 Khabarovsk SYd 8.10.1962 18.7.1964 29.9.1965 stricken 6.1985 Project 204
МПК-20 [MPK-20]   506 Khabarovsk SYd 20.11.1962 26.8.1965 31.12.1965 target 6.1983 Project 204
МПК-111 [MPK-111]   507 Khabarovsk SYd 30.7.1963 26.4.1966 30.9.1966 stricken 6.1988 Project 204
МПК-112 [MPK-112]   508 Khabarovsk SYd 24.9.1964 15.7.1966 30.12.1966 stricken 8.1984 Project 204
МПК-114 [MPK-114]   509 Khabarovsk SYd 25.9.1965 26.4.1967 30.9.1967 stricken 6.1987 Project 204
МПК-134 [MPK-134]   510 Khabarovsk SYd 25.1.1966 29.7.1967 30.11.1967 stricken 7.1986 Project 204
МПК-136 [MPK-136]   511 Khabarovsk SYd 25.8.1966 12.10.1967 31.7.1968 stricken 6.1987 Project 204
МПК-134 [MPK-134]   822 Zaliv, Kerch' 15.7.1967 4.5.1968 30.9.1968 to Romania 12.1968 (V31) Project 204E
МПК-124 [MPK-124]   823 Zaliv, Kerch' 25.4.1968 12.9.1968 30.12.1968 to Romania 4.1969 (V32) Project 204E
МПК-44 [MPK-44]   824 Zaliv, Kerch' 8.12.1968 19.6.1969 15.9.1969 to Romania 10.1969 (V33) Project 204E


Technical data


Displacement standard, t

801-804: 410

others pr. 204: 439

pr. 204E: 436

Displacement normal, t

801-804: 510

others pr. 204: 555

pr. 204E: 546

Length, m

58.6

Breadth, m

8.13

Draught, m

801-804: 2.94

others pr. 204: 3.09

pr. 204E: 3.06

No of shafts

2 with hydroturbines

Machinery

801-804, 813, pr. 204E: CODAG: 2 D-2B gas turbines + 2 M-503V diesels

others pr. 204: CODAG: 2 D-2B gas turbines + 2 M-504A diesels

Power, h. p.

801-804, 813, pr. 204E: 36600 (30000 + 6600)

others pr. 204: 39500 (30000 + 9500)

Max speed, kts

801-804, 813, pr. 204E: 32

others pr. 204: 35

Fuel, t

oil

Endurance, nm(kts)

pr. 204: 2650(13.7)

pr. 204E: 2500(13.5)

Armament

801-804: 1 x 2 - 57/75 ZIF-31B, 4 x 1 - 400 TT, 2 x 16 RBU-2500 Smerch ASWRL

others pr. 204: 1 x 2 - 57/50 AK-725, 4 x 1 - 400 TT, 2 x 12 RBU-6000 Smerch-2 ASWRL

pr. 204E: 1 x 2 - 57/50 AK-725, 2 x 1 - 533 TT, 2 x 16 RBU-2500 Smerch ASWRL

Electronic equipment

801-804: MR-302 Rubka, Donets radars, GS-572 Gerkules-2M sonar, Bizan'-4B ECM suite

others pr. 204: MR-302 Rubka, MR-103 Bars, Donets radars, MG-312 Titan-2 sonar, Bizan'-4B ECM suite

pr. 204E: MR-302 Rubka, MR-103 Bars, Donets-2, GS-572 Gerkules-2M sonar, Bizan'-4A ECM suite

Complement

pr. 204: 55

pr. 204E: 52



Standard scale images


<i>MPK-45 </i>1964
MPK-45 1964
<i>MPK-72 </i>1979
MPK-72 1979


Graphics


Project 204
Project 204


Project history

These were the first large Soviet gas turbine warships, using a new M-2 engine to achieve 38kts; they were also the fastest ASW ships the Soviets ever built. The two propellers were mounted in thrust tubes the length of the poop, which contains the two turbines; the latter exhaust through ports above them in the transom, and also drive air compressors whose output was exhausted into the propeller tubes, to add thrust.

Modernizations

1970, MPK-150: + VGS-2 Oka-M sonar

1970s, MPK-74, MPK-83: + MG-7 Braslet sonar

1970s, MPK-74: + 2 UB-16-57UMP decoy launchers

1989, MPK-74: - 2 UB-16-57UMP decoy launchers; + 2 PK-16 decoy launchers

Naval service

No significant events.
