No12 small submarine chasers (project PP-19-OK) (1943 - 1945)
Ships
| Names | Builders | Commissioned | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
№42 [No42], 10.1944- СК-178 [SK-178] №52 [No52], 10.1944- СК-52 [SK-52] №62 [No62], 10.1944- СК-62 [SK-62] №72 [No72], 10.1944- СК-72 [SK-72] №82 [No82], 10.1944- СК-82 [SK-82] №92 [No92], 10.1944- СК-179 [SK-179] №122 [No122] №132 [No132], 10.1944- СК-132 [SK-132] №142 Старый Большевик [No142 Staryy Bolshevik], 10.1944- СК-142 Старый Большевик [SK-142 Staryy Bolshevik] №152 [No152], 10.1944- СК-152 [SK-152] №162 [No162], 10.1944- СК-180 [SK-180] MO-588 - 596 MO-600, 601 МО-603 Юнга Севера [MO-603 Yunga Severa] MO-604 - 611 MO-613 - 617 СК-171 - 177 [SK-171-177] СК-272 [SK-272] СК-282 [SK-282] СК-292 [SK-292] |
5 Yd, Leningrad: No42, 52, 62, 72, 82, 92, 122, 142, 152, MO-588-596, 600, 601, 603-611, 613-617, SK-171-177, SK-272, SK-282, SK-292 |
1943: No42, 52, 62, 72, 82, 92, 122, 132, No142 Staryy Bolshevik, No152, 162, SK-175 - 177, 272, 282, 292 1944: MO-588 - 596, 600, 601, 615 - 617, SK-171 - 174 1945: MO-603 Yunga Severa, MO-604 - 611, 613, 614 |
MO-594 (24.12.1944), MO-595 (6.5.1945), SK-62 (18.11.1944), No122 (14.5.1944), SK-176 (14.2.1944), SK-177 (14.2.1944) |
none |
1948: 1949: MO-588 - 593, 596, 615 - 617, SK-37, 175, 178, 292 1950: SK-176,, 177, 179, 272 1954: MO-600, 601, MO-603 Yunga Severa, MO-604 - 614, SK-52, 72, 82, 132, SK-142 Staryy Bolshevik, SK-152, 174, 180, 282 1956: SK-171 - 173 |
Technical data
| Displacement standard, t | 37 |
|---|---|
| Displacement full, t | 40 |
| Length, m | 22.2 |
| Breadth, m | 4.04 |
| Draught, m | 1.78 |
| No of shafts | 3 |
| Machinery | 2 GAM-34BS petrol engines + 1 ZIS-5 petrol engine |
| Power, h. p. | 2200 + 85 = 2285 |
| Max speed, kts | 24 |
| Fuel, t | petrol 5 |
| Endurance, nm(kts) | 1000(6) |
| Armament | 1 x 1 - 37/63 70K, 2 x 1 - 12.7/79 or 2 x 2 - 12.7/79, 2 x 4 - 82 M-8 RL (on some), 2 DCR (6) |
| Electronic equipment | Tamir-1 sonar |
| Complement | 11 |
Standard scale images
No42 1943
Graphics
Project history
Small chasers in hull of type D-3 MTB. Original design was used with minimum alterations. Instead of torpedoes 37mm MG 70K was installed aft. Engine on the central shaft was replaced by cruising automobile motor. 10 additional boats were converted from D-3 type MTBs.
Modernizations
None.
Naval service
No significant events.
