P-274 inshore patrol boats (project 03160) (2015-)





P-838 2015

Ships


Names Builders Completed Losses Transfers Discarding

П-274-276 [P-274-276]

П-281 [P-281]

П-342 [P-342], 10.2016- Юнармеец Балтики [Yunarmeets Baltiki]

П-344 [P-344]

П-345 [P-345]

П-413 [P-413]

П-415 [P-415]

П-425 [P-425]

П-838 [P-838]

П-845 [P-845]

5 more units

Pella, Otradnoye: P-274-276, 281, 342, 344, 345, 413, 415, 425, 838, 845, 5 more units

2015: P-274-276, 281, 342, 344, 838, 845

2017: P-345, 413, 415, 425

2018: 2 units (YNo 713, 714)

planned 2019: 3 boats (YNo 715-717)

none

none

in service (2019): P-274-276, 281, 342, 344, 345, 413, 415, 425, 838, 845, 2 more units



Technical data


Displacement standard, t
Displacement full, t

23

Length, m

16.7

Breadth, m

4.00

Draught, m

0.85

No of shafts

2 waterjets

Machinery

2 Caterpillar C18 diesels

Power, h. p.

2300

Max speed, kts

48

Fuel, t

diesel oil

Endurance, nm(kts)

300(35)

Armament

all except P-344: 1 x 1 - 14.5/89, 2 x 1 - 7.6/90

P-344: light arms

Military load20 marines
Electronic equipmentNautilus radar
Complement

3



Standard scale images


<i>P</i><i>-344 </i> 2015
P-344 2015


Graphics


<i>P-838 </i>2015
P-838 2015


Project history

Fast patrol craft, licensed copy of Swedish CB-90. Intended for patrol duties, harbour defence, inshore and riverine combat operations, landing and recovery of special forces, search and rescue operations. Marines can be landed via bow ramp.

Modernizations

None.

Naval service

No significant events.
