KT-83 torpedo attack craft (project 183, 1956 - 1958)





KT-72 1971

Ships


Names Builders Completed Losses Transfers Discarding

401 KT-83

402 KT-84

403 KT-85

404 KT-86

405 KT-87

406 KT-88

407 KT-89

408 KT-90

409 KT-71

410 KT-72

411 KT-73

412 KT-74

413 KT-75

414 KT-76

415 KT-77

416 KT-78

417 KT-79

418 KT-80

419 KT-91

420 KT-92

5 Yd, Leningrad, USSR: KT-71-80, 83-92

// 1956: KT-83-87

// 1957: KT-88-90

// 1958: KT-71-80, 91, 92

none

none

1966: KT-88

1967: KT-83, 84, 86, 87

1968: KT-76, 85, 89

1969: KT-72, 77

1970: KT-74, 75, 80, 90

1971: KT-71, 73, 78, 79, 91, 92



Technical data


Displacement standard, t

57

Displacement full, t

67

Length, m

25.5

Breadth, m

6.18

Draught, m

1.24

No of shafts

4

Machinery

4 M-50FTK diesels

Power, h. p.

6000

Max speed, kts

43

Fuel, t

diesel oil

Endurance, nm(kts)

1000(14)

Armament

2 x 2 - 25/112 2M-3M, 2 x 1 - 533 TT or 18 mines, 8 DC

Electronic equipment

Zarnitsa radar

Complement

14



Standard scale images


<i>KT-83 </i>1960
KT-83 1960


Graphics


<i>KT-72 </i>1971
KT-72 1971


Project history

Soviet project 183 boats.

Modernizations

None.

Naval service

No significant events.
