Amazonas 1935

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Amazonas	CF11, 1960- 11		Electric Boat, Groton, USA		1934	7/1935	in service (2019)
Loreto	CF12, 1960- 12		Electric Boat, Groton, USA		1934	7/1935	in service (2019)

Technical data

Displacement standard, t	250
Displacement full, t
Length, m	44.1 pp 46.7 oa
Breadth, m	6.71
Draught, m	1.37
No of shafts	2
Machinery	2 diesels
Power, h. p.	750
Max speed, kts	15.5
Fuel, t	diesel oil
Endurance, nm(kts)	4000(10)
Armament	4 x 1 - 76/50 Mk 20, 2 x 1 - 47/40 Hotchkiss, 2 x 1 - 7.7/94
Electronic equipment	none
Complement	35

Standard scale images

Graphics

Project history

Built for service on upper Amazon. Boats differed from "classical" river gunboats by "laconic" outline profile, diesel machinery and DP guns.

Modernizations

1960s, both: - 2 x 1 - 76/50, 2 x 1 - 47/40, 2 x 1 - 7.7/94; + 4 x 1 - 40/60 Mk 3, 2 x 1 - 20/70 Mk 4, radar

1980s: - old radar; + Furuno radar

Naval service

No significant events.
