Rio Segovia 2006

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
304, 305 307 309 311 313 315 317 319 321 323 later 2 units were renumbered: 301, later- 301 Rio Segovia 302	More, Feodosiya, USSR: 304, 305, 307, 309, 311, 313, 315, 317, 319, 321, 323	1982: 304 1983: 305 1984: 307 1986: 309, 311, 313, 315, 317 1980s // 1989: 319, 321, 323	1 unit (hurricane 10.1989), 1 unit (hurricane 10.1989)	none	1991-1994: 6 units late 1990s: 1 unit 2005: 302 2012: 301

Technical data

Displacement standard, t	37
Displacement full, t	40
Length, m	23.8
Breadth, m	5.15
Draught, m	1.00
No of shafts	2
Machinery	2 M-401BT diesels
Power, h. p.	2000
Max speed, kts	29
Fuel, t	diesel oil
Endurance, nm(kts)	400(12)
Armament	1 x 2 - 12.7/79 or 2 x 2 - 12.7/79 or 1 x 2 - 14.5/89 or 2 x 2 - 14.5/89
Electronic equipment	MR-241 Pechora-1 radar
Complement	9

Graphics

Project history

Soviet export project 1400ME boats. Last three boats were transferred from Cuban Navy.

Modernizations

None.

Naval service

No significant events.
