K III Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
K III		161	De Schelde, Vlissingen	7.1915	12.8.1919	7.1920	stricken 1934
K IV		164	De Schelde, Vlissingen	12.1915	2.7.1920	4.1921	stricken 1936

Technical data

Displacement standard, t
Displacement normal, t	583 / 721
Length, m	64.4
Breadth, m	5.60
Draught, m	3.56
No of shafts	2
Machinery	K III: 2 MAN 8-cyl diesels / 2 electric motors K IV: 2 Sulzer 6-cyl diesels / 2 electric motors
Power, h. p.	K III: 1800 / 630 K IV: 1200 / 630
Max speed, kts	K III: 16.5 / 8.5 K IV: 15 / 8.5
Fuel, t	diesel oil
Endurance, nm(kts)	3500(11) / 25.5(8.5)
Armament	1 x 1 - 75/52 SA No.2, 6 - 450 TT (2 bow, 2 stern, 1 x 2, 12)
Complement	29
Diving depth operational, m	40

Standard scale images

Graphics

Project history

Holland type. Double-hulled.

Modernizations

late 1920s, both: + 1 x 1 - 12.7/90

Naval service

No significant events.
