Arend 1933 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Arend		311	Wilton-Fijenoord, Schiedam		21.5.1929	1929	scuttled 1.3.1942
Valk		312	Wilton-Fijenoord, Schiedam		19.10.1929	1929	scuttled 8.3.1942

Technical data

Displacement standard, t	748
Displacement full, t	1011
Length, m	70.0 pp 71.9 oa
Breadth, m	9.00
Draught, m	2.82
No of shafts	2
Machinery	2 VTE, 2 boilers
Power, h. p.	3350
Max speed, kts	18
Fuel, t	oil 275
Endurance, nm(kts)	1400 (10)
Armament	2 x 1 - 75/52 SA Nr.2, 1 x 1 - 7.9/80, 1 seaplane (WA)
Complement	61

Standard scale images

Graphics

Project history

Gouvernementsmarine ships intended for service in East Indies.

Modernizations

None.

Naval service

Arend was scuttled at Tadjong Priok 1.3.1942, salvaged by Japanese, commissioned by IJN as patrol No108, returned in 1945 and finally sunk as a target in 1948. Valk was scuttled at Tjilatjap 8.3.1942, salvaged by Japanese, commissioned by IJN as patrol No104 and mined off Maizuru 24.8.1945.
