NAVYPEDIA


D18 1976

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
DM01 (ex-Jubilant), 1994- General Miguel Negrete	D1, 1994- C50		American SB, Lorain, USA	10.1942	20.2.1943	8.1943 // 10.1962	stricken 2000
DM02 (ex-Hilarity)	D2		Commercial Ship Repair, Winslow, USA	3.1944	30.7.1944	11.1944 // 10.1962	deleted 1986
DM03 (ex-Execute), 1994- General Juan N. Méndez	D3, 1994- C51		Puget Sound Bridge, USA	3.1944	22.6.1944	11.1944 // 10.1962	stricken 7.2001
DM04 (ex-Facility)	D4		Puget Sound Bridge, USA	3.1944	22.6.1944	11.1944 // 10.1962	stricken 4.1973
DM04 (ex-Specter), 1994- General Manuel E. Rincón	D4, 1994- C52		Associated, Seattle, USA	5.1943	15.2.1944	8.1944 // 4.1973	stricken 7.2001
DM05 (ex-Scuffle), 1994- General Felipe Xicoténcatl	D5, 1994- C53		Commercial Ship Repair, Winslow, USA	5.1943	8.8.1943	5.1944 // 10.1962	foundered 1999
DM06 (ex-Eager)	D6		American SB, Lorain, USA	12.1943	10.6.1944	11.1944 // 10.1962	deleted 1986
DM07 (ex-Recruit)	D7		General Engineering, Alameda, USA	5.1943	11.12.1943	11.1944 // 10.1962	deleted 1970
DM08 (ex-Success)	D8		Associated, Seattle, USA	2.1944	11.5.1944	10.1944 // 10.1962	deleted 1970
DM09 (ex-Scout)	D9		Commercial Ship Repair, Winslow, USA	2.1943	2.5.1943	3.1944 // 10.1962	deleted 1970
DM10 (ex-Instill)	D0		Savannah Machine & Foundry Co., USA	11.1943	5.3.1944	5.1944 // 10.1962	deleted 1986
DM11 (ex-Device), 1994- Cadete Agustín Melgar	E1, 1994- C54		Tampa SB, USA	7.1943	21.5.1944	7.1944 // 10.1962	stricken 2000
DM12 (ex-Ransom), 1994- Teniente Juan de la Barrera	E2, 1994- C55		General Engineering, Alameda, USA	4.1943	18.9.1943	8.1944 // 10.1962	stricken 2000
DM13 (ex-Knave), 1994- Cadete Juan Escutia	E3, 1994- C56		American SB, Lorain, USA	10.1942	13.3.1943	10.1943 // 10.1962	stricken 2000
DM14 (ex-Rebel), 1994- Cadete Fernando Montes de Oca	E4, 1994- C57		General Engineering, Alameda, USA	5.1943	28.10.1943	9.1944 // 10.1962	stricken 7.2001
DM15 (ex-Crag), 1994- General Pedro María Anaya	E5		Tampa SB, USA	12.1942	21.3.1943	8.1944 // 10.1962	stricken 1994
DM16 (ex-Dour)	E6		American SB, Lorain, USA	10.1943	25.3.1944	11.1944 // 10.1962	deleted 1986
DM17 (ex-Diploma), 1994- Cadete Francisco Márquez	E7, 1994- C59		Tampa SB, USA	7.1943	21.5.1944	7.1944 // 10.1962	stricken 2000
DM18 (ex-Invade), 1994- General Ignacio Zaragoza	E8, 1994- C60		Savannah Machine & Foundry Co., USA	1.1944	6.2.1944	9.1944 // 10.1962	stricken 7.2001
DM19 (ex-Intrigue), 1994- Vicente Suárez	E9, 1994- C61		Savannah Machine & Foundry Co., USA	12.1943	8.4.1944	7.1944 // 10.1962	stricken 7.2001
DM20 (ex-Harlequin), 1978- Oceanográfico, 1994- General Pedro María Anaya, 1999- Aldebarán	E0, 1978- H02, 1994- A08, 1999- BE02		Puget Sound Bridge, USA	8.1943	3.6.1944	8.1945 // 10.1962	survey vessel 1978, TS 1994, stricken 2008

Technical data

Displacement standard, t	825
Displacement full, t	945
Length, m	54.9 wl 56.2 oa
Breadth, m	10.1
Draught, m	2.97
No of shafts	2
Machinery	2 diesels
Power, h. p.	2000
Max speed, kts	15.1
Fuel, t	diesel oil 140
Endurance, nm(kts)	8500 (12)
Armament	1 x 1 - 76/50 Mk 21, 2 x 2 - 40/60 Mk 1, 4 x 2 - 20/70 Mk 24 or (2 x 2 - 20/70 Mk 24, 2 x 1 - 20/70 Mk 10)
Electronic equipment	SO-13, SPS-5 radars
Complement	96

Standard scale images

Graphics

Project history

Former USN PCE class patrol craft, escorts.

Modernizations

1990s, mostly: - SO-13 radar; + Kelvin Hughes 14/9 radar

Naval service

No significant events.

1976
