Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
10 boats	USSR: 6 boats North Korea: 4 boats	1957-1962 // 1962: 6 boats 1960s: 4 boats	none	none	early 1980s: 2 boats early 1990s: 2 boats in service (2019): 6 boats

Technical data

Displacement standard, t	70
Displacement full, t	81
Length, m	25.5
Breadth, m	6.20
Draught, m	1.40
No of shafts	4
Machinery	4 M50F-4 diesels
Power, h. p.	4800
Max speed, kts	38
Fuel, t	diesel oil
Endurance, nm(kts)	885(11.8)
Armament	2 x 1 P-15 SSM (2 P-15), 1 x 2 - 25/80 2M-3M
Electronic equipment	Rangout radar
Complement	17

Standard scale images

Graphics

Project history

Six Project 183R boats were transferred from USSR and four built locally.

Modernizations

none

Naval service

No significant events.
