Jasiri 2013

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Jasiri	P3124		Gondan, Castropol, Spain	2004	1.2005	27.8.2012	in service (2020)

100 - 1000 t displacement/ BRT tonnage vessels

Name No Yard No Builder Laid down Launched Comp Fate Jasiri P3124   Gondan, Castropol, Spain 2004 1.2005 27.8.2012 in service (2020)

Technical data

Displacement standard, t
Displacement full, t	1020
Length, m	76.5 pp 84.5 oa
Breadth, m	12.2
Draught, m	3.00
No of shafts	2
Machinery	2 MTU 20V1163 TB93 diesels
Power, h. p.	20000
Max speed, kts	26
Fuel, t	diesel oil
Endurance, nm(kts)	5500(12)
Armament	2 x 1 - 25/80 KBA, 2 x 1 - 12.7/90, 2 x 1 - 7.6/90
Electronic equipment	Furuno FAR-2835S, Kelvin-Hughes 2007 radars
Complement	41 + 20 passengers

Graphics

Project history

Originally ordered in 2003. Though launched in 2005, the ship was the subject of numerous political, economic and technical disputes prior to the reaching of agreement for purchase in April 2012: standby crew returned to Kenya in July 2005 and the ship was laid up near La Coruña for six years. Can be used also for survey and hydrographic duties.

Modernizations

2016: + 1 x 1 - 57/70 SAK-57 Mk 1, 1 x 6 - 30/54 AK-630

Naval service

No significant events.
